WT931 500Hz AHRS IMU Sensor 3 Axis Angle + Accelerometer + Gyroscope + Magnetometer MPU-9250 Module Geekcreit for Arduin

Manual Click here to open Features Module integrates high precision gyroscopes accelerometer geomagnetic sensor high performance microprocessors and advanced dynamics solves dynamic Kalman filter algorithm to quickly solve the current real time movement of the module attitude The use of advanced digital filtering technology can effectively reduce the measurement noise and improve measurement accuracy Integrates gesture solver with dynamic Kalman filter algorithm can get the accurate attitude in dynamic environment attitude measurement precision is up to 0 05 degrees with high stability performance is even better than some professional Inclinometer Working voltage is 3 3v 5v Highest 500Hz output data rate The data rate can be adjusted 0 1 500HZ 4 layer PCB technology thin smaller and more reliable Package size is PLCC 28 convenience to embed in PCB board Note So as not to interfere with the magnetometer do not route under the MPU9250 chip Specifications 1 Voltage 3 3V2 Consumption current 25mA3 Volume 12mm X 12mm X 2mm4 Pad spacing Up and down 1 27mm Left and Right 12mm5 Measuring dimensions Acceleration X Y ZAngle X Y ZGyro X Y ZMagnetic field X Y Z6 Range Acceleration 2 4 8 16gangular rate 250 500 1000 2000 sAngle X Z 180 Y 90 7 7 Stability Acceleration 0 01g Angular speed 0 05 s 8 Angle accuracy X Y dynamic 0 1static 0 05 Z axis 1 No magnetic interference and aftercalibration 9 Data output Time A
