BNO080 AR VR IMU Nine Axis 9DOF AHRS/IMU Sensor Module High Accuracy Accelerometer Gyro Magnetometer Virtual Reality 3D

More document click to download: BNO08 Product Introduction: The BNO080 / 085 is a 9-axis system-in-package (SiP) that enables rapid development of sensor-enabled augmented reality (AR) virtual reality (VR) robotics and IoT devices. Featuring high-performance accelerometers, magnetometers and gyroscopes, the low-power 32-bit ARM Cortex M0 + MCUs are available in a small package. Interfaces: The BNO080 can communicate through a variety of interfaces. The Qwiic VR IMU has two jumpers that allows the user to select their interface of choice. I2C (Default): Up to 400kHz SPI: Up to 3MHz UART: 3Mbps UART-RVC (Robot Vacuum Cleaners): 115200kbps Performance Characteristics: Rotation Vector Dynamic Error: 3.5 Static Error: 2.0 Gaming Rotation Vector Dynamic Error: 2.5 Static Error: 1.5 Heading Drift: 0.5 / min Geomagnetic Rotation Vector Dynamic Rotation Error: 4.5 Static Rotation Error: 3.0 Gravity Angle Error: 1.5 Linear Acceleration Accuracy: 0.35m/s2 Accelerometer Accuracy: 0.3m/s2 Gyroscope Accuracy: 3.1 / sec Magnetometer Accuracy: 1.4T Package Included: 1 x BNO080 AR VR IMU Nine Axis 9DOF AHRS/IMU Sensor Module
