RANMEI SOIC8 SOP8 test clip free chip test burning clip wide and narrow body universal

Describe Note: The light clip is only a clip head (no solders wires and no board) Before you buy: Some boards can directly clip the chip but some boards cannot be operated in this way because the chip will be affected by the peripheral circuit on the board please know before shootings so as not to buy it back and use it but soldering the chip is quite a universal socket. The same can be used directly and both wide and narrow bodies are common. Many high-power programmers can basically be used normally When encountering a programmer with a protected function the clip cannot be read under normal voltage. At this time a 3.3V voltage needs to be added. The method is: The clip clamps the chip corresponding to the 8th pin of the chip Apply a 3.3V voltage to the clip pin. Generally the 3.3V power supply has two wires so the VCC corresponds to the clip and the other wire is directly grounded. Feature *SOIC8 SOP8 test clip SOP8 chip test and burning clip are universal in width and narrow body *Clamp chip bevel design better and more reliable clamping IC contact *Each pin is fully gold-plated the quality is more reliable Precautions and common problems and solutions 1. The pins of the clip are dense and the pitch is 1.27 so the Dupont wire cannot be inserted directly. It is necessary to cut the Dupont wire end and solder it on it (be careful not to short circuit). 2. When clipping the IC the 8 pins of the chip should correspond to the 8 pins on the adapter so the welding line should pay attention to this problem. 3. Some boards can directly clip the chip and some boards cannot directly clip the chip because the chip will be affected by the peripheral circuit on the board but the chip can be directly used as a general-purpose socket after soldering and the wide body The other end of the narrow-body DuPont line can be directly inserted into the adapter board. 4. The other end of the DuPont cable can be directly plugged into the adapter board. Packing list: 1*Test clip
