Mingyiq Test clip for CH341A Flash BIOS USB programmer and SOIC8 SOP8 chip IC adapter

Features: - brand new and high quality - Made of high quality materials durable - Suitable for amateur programmers 24 and 25 series flash. - Use dedicated CH341A chip USB. USB1.1 communication. - Erase programming speed is about 2-3Mbit checks per minute. - Programming speed is 2-3 times faster than ordinary ATMEGA8 25 series programmers. - Using FT232BL chip external EEPRON (93C46) - Support 3 power supply modes: 5V external power supply; 3.3V external power supply; external power supply (requires 3.3V-5V) - With 3 LEDs: TXD LED RXD LED POWER LED - GND RXD TXD 3V3 5V: bend pin headers - Other functional pins: reserved pads CTS RTS Instructions for use: (taking access to MCU as an example) -GND: Connect to GND -RXD: connect MCU.TX (signal : MCU.TX >> FT232 >> PC.RX) -TXD: connect MCU.RX (signal : MCU.RX > FT232 >> PC.CTS) Product parameters: - Colour: Black - Quantity: 1pcs - Model: Test clip - Special service: no-disassembly SOP8 test clip - Style: straight foot curved foot (optional) Package Included: 1* Test clip (optional) Notes: 1. Due to various factors such as display brightness and light brightness the actual color of the product may be slightly different from the website picture. 2. Please allow a slight deviation between the data and the manual measurement.
