MSI MPG Z690 Carbon WIFI LGA 1700 SATA 6Gb/s ATX Gaming Motherboard
Combining 2x 8-pin power connectors and premium layout design, that is ready for unleashing the maximum performance.Premium PCB Material8 layer PCB with the use of server grade material and 2oz thickened copper provides higher performance and long-lasting system stability without any compromise.Audio Boost 5Isolated audio with high quality audio processor & amp for the most immersive gaming experience.Direct 18+1+1 Power Design with Digital PWMAn aggressive digital VRM power design with digital PWM IC and direct 18 phases power system with 75A Smart Power Stage, make sure your system runs smoothly under the most extreme conditions.PCI-E Steel ArmorProtecting VGA cards against bending and EMI for better performance, stability and strength.Premium Thermal SolutionPremium Thermal DesignHeavy plated MOSFET heatsink with heat-pipe, high quality 7W/mK MOSFET thermal pads and extra thermal pads ensure all cores running in high performance.M.2 Shield FrozrStrengthened built-in M.2 thermal solution. Keeps M.2 SSDs safe while preventing throttling, making them run faster.Pump Fan SupportControl watercooling pump speeds for best flow and noise control.Enlarged Chipset HeatsinkLarger heatsink for chipset ensures better heat dissipation and cooling effects.High-Speed Transmission2.5G Network SolutionFeaturing premium 2.5G LAN with LAN manager delivers better network experience.Intel Wi-Fi 6EThe latest wireless solution supports 6GHz spectrum, MU-MIMO and BSS color technology and delivering speeds up to 2400Mbps.Lightning USB 20GBuilt-in USB 3.2 Gen 2x2 port, offers the 20Gbps transmission speed, 4X faster than USB 3.2 Gen 1.Memory BoostThe fully isolated DOR circuit to deliver pure data signals for the best gaming and overclocking performance.Lightning Gen 5 SolutionThe latest Gen 5 PCI-E slots with up to 128GB/s bandwidth for maximum transfer speed.Premium Hardware DesignWith years of experience, MSI is no stranger to building high-performance motherboards. Our R&D and engineering teams have reviewed countless designs, evaluated a wide selection of high quality components, and developed products for reliability even under extreme conditions.CoolingM.2 Shield FrozrWorld's fastest SSDs can start to lower performance when getting hot. Part of the motherboards heatsink design, M.2 Shield Frozr is the next generation M.2 thermal solution to avoid this by offering the best thermal protection to make sure that SSD maintains maximum performance.Frozr AI CoolingDetecting CPU & GPU temperatures and automatically adjusting fan duty of system fans to a proper value by adopting MSI AI ENGINE.Fully Controllable in BIOS and SoftwareMSI motherboards let you manage speeds and temperatures for all your system and CPU fans. Total Fan Control allows you check your primary system characteristics in a simplified graphical interface. You can also set up to 4 temperature targets for CPU and motherboard, which will adjust the fan speeds automatically.Autodetect DC or Pwm Mode with HysteresisMSI fan headers automatically detect fans running in DC or PWM mode for optimal tuning of fan speeds and silence. Hysteresis also makes your fans spin up fluently to make sure your system stays silent, no matter what.DIY 2.0 - Integrating With The System EnvironmentConnect and synchronize with MSI coolers and cases with strategically positioned pin-header locations including a dedicated pump-fan header.Optimized for Water CoolingDesigned to support the most popular All-In-One & customized water cooling solutions on the market. A dedicated water pump PIN header supports up to 3 amp, giving you full control of the water pump speed. A clearly marked 'keep-out-zone' allows for easy and safe installation and a perfect fit.Power SolutionDirect 18 + 1 +1 Phases Power DesignUnleash and sustain maximum performance with an aggressive VRM design built with a total of direct 18 +1+1 power phases. Combining 2x 8-pin power connectors and exclusive Core Boost technology, MPG series motherboard is ready to sustain heavy daily work.Core BoostCore Boost technology combines MSI's premium layout and digital power design which allows for faster and undistorted current delivery to the CPU at pin-point precision. Not only supporting multi-core CPU, also creating the perfect conditions for your CPU overclocking.More For PerformanceLoad-Line CalibrationWhat you set, is what you get. LLC makes sure your CPU voltage remains 100% stable under any load. This greatly improves stability when demanding more CPU performance.Overvoltage ProtectionPrevents potential short-circuit damage to the CPU and other critical components.Digitall Power DesignA fully digital power design allows for faster and undistorted current delivery to the CPU at pin-point precision. Creating the perfect conditions for CPU overclocking.Double Power ConnectorsTwo 8-pin connectors deliver adequate power even for an overclocked multi-core CPU.1-Second Overclocking!MSI Game Boost enables one-second overclocking, giving you the performance boost you need to get more FPS.DIY FriendlyEZ M.2 ClipHave trouble turning screws? MSI innovative EZ M.2 clip assist you install an M.2 SSD quickly and effortlessly.Avoid Collision NotificationProtective paint is printed around each screw hole to prevent parts from being scratched.Keep Out ZoneMSI motherboards circuitry ensure the case standoff keep out zones are pure and clean, preventing any component contact or damage to the motherboard.Pre-Installed I/O ShieldFeaturing the Pre-installed I/O Shield, makes your installation process easier and safer. The patent-pending design protect your IO ports and also prevent electrostatic discharge damage, makes your motherboard a strong gaming foundation.More User Friendly EnhancementsXL ClipThe enlarged PCI-E clip helps you swap or remove your devices easier. Keep the PCI-E slot stronger and safer.EZ Debug LEDRun into trouble? Onboard LEDs for key components will indicate the source of the problem so you know exactly where to look to get up and running again.EZ LED ControlA built-in LED button on the motherboard to control your light effect. Turn on/off your light in a second!Protection
PCB DesignThe PCB design has been optimized for higher bandwidth and faster transfer speeds, which is also beneficial for reliable circuit transmission.• 8 PCB layers• IT-170 Server-grade PCB material• 2oz Thickened CopperFortify Your System With Pci-E Steel ArmorMSI PCI Express Steel Armor slots are secured to the motherboard with extra solder points and support the weight of heavy graphics cards. When every advantage in games counts, Steel Armor shields the point of contact from electromagnetic interference.Ultimate Motherboard ProtectionDouble ESD protection doubles up the grounding layer around the mounting holes, preventing static discharge surges from damaging the motherboard.Windows 11 CertifiedWith MSI you benefit from great compatibility and a worry-free user experience when using Microsoft Windows 11. With a true dedication to performance, our R&D team has made sure everything works as intended when using the latest version of Microsoft Windows on any MSI product.Certified For GamingMSI motherboards has been built and tweaked for hardcore gaming. Feedback from the world's best esports players and rigorous testing sessions with demanding PC games has resulted in a motherboard that's both powerful and reliable.Enhanced PerformanceHigh performance MSI motherboards are loaded with advanced features and the latest technology to overwhelm any challenge at hand no matter whether you're a gamer, prosumer, or PC enthusiast.MemoryLatest DDR5 MemoryA huge step of DDR performance enhancement with the latest DDR5 memory. Combines with dedicated SMT welding process and MSI Memory Boost technology, MPG Z690 CARBON WIFI is ready to deliver the world class memory performance.Extreme Stability & Compatibility TestingMSI conducts thorough memory testing with the most popular memory brands under extreme conditions to ensure your system runs stable no matter what. Our memory partners include brands like Corsair, Crucial, Kingston, G.Skill and many more to optimize memory modules, configurations and even improve overclocking. SMT DDR5 Memory SlotThe advanced SMT(Surface Mount Technology) welding process reduces the defect rate of slot solder joints, electromagnetism, and interference. Combining with exclusive Memory Boost technology allows MSI motherboards to deliver the clean and pure high-frequency DDR5 signal. Easy Overclocking With XMP ProfileThe XMP (Extreme Memory Profiles) in MSI BIOS are tested and certified by MSI OC LAB. It is easy to enable with auto power settings to get the best memory speed and stability.
