MSI MEG Z690 UNIFY-X LGA 1700 SATA 6Gb/s ATX Gaming Motherboard
Fully aluminum 10 cover and extended heatsink design provide the maximum surface of heat dissipation.
Double side M.2 Shield FrozrDouble-sided M.2 thermal solution keep M.2 SSDs safe while preventing throttling, making them run cooler and faster.
Heat-pipe DesignConnecting two MOS heatsinks to enlarge the surface of heat dissipation.
Aluminum BackplateThe aluminum baseplate cools down your Mosfet with dedicated thermal pad.
Unlimited ConnectivityDual 2.5G LANOnboard dual 2.56 LAN with LAN manager deliver the best online experience without lag.Latest Wi-Fi 6E SolutionThe latest wireless solution supports 6GHz spectrum, MU-WINO and KS color technology, delivering speeds up to 2400Mbps.Lightning Gen 5 PCI-EMSI Lightning Gen 5 PCI-E represents the bandwidth of x16 interface to 128GB/s, which is double of the speed of the previous generation.
Extreme DDRS Memory OC The top-notch R&D design and exclusive 2 DIMM solution for an even clearer DDR5 memory signal to deliver the world class memory performance.Front and Rear USB 20GLightning USB 3.2 Gen 2x2 port offers 20Gbps transmission speed, 4X faster than USB 3.2 Gen 1.
Quintuple M.2 ConnectorsOnboard 5x M.2 connectors with quadruple PCIe 4.0 solution, strengthened by double-sided M.2 Shield Frozr.
Stable Cornerstone of Your System
8-Layer Server Grade PCBServer grade and multilayer printed circuit boards optimized the system stability, makes your system runs stable and cool.
2oz Thickened Copper2oz thickened copper PCB provides higher performance and long-lasting system stability.
PCIe Steel ArmorProtecting VGA cards against bending and EMI for better performance, stability and strength.
Direct 19+2 Power Phases with 105A SPSHighest quality components with direct digital power, 105A Smart Power Stage and titanium choke III make sure your system runs smoothly under the most extreme conditions.
Smart ButtonOne button with multiple hardware control. Reset Computer, Safe Boot Turbo Fan and EZ LED control functions with just one click.
Advanced SMT ProcessThe advanced SMT(Surface Mount Technology) welding process reduces the defect rate of slot solder joints, electromagnetic and interference, deliver the clean and pure signal.
The World Record Breaker - MEG MotherboardPremium Hardware DesignWith years of experience, MSI is no stranger to building high-performance motherboards. Our R&D and engineering teams have reviewed countless designs, evaluated a wide selection of high quality components, and developed products for reliability even under extreme conditions.CoolingThermal Solution for More Cores and Higher PerformanceWith more cores' processors, thermal and power design is more important to make sure the temperature keeps lower. MSI extended PWM heatsink and enhanced circuit design ensures even high-end CPU to run in full speed with MSI motherboards.
Double Side M.2 Shield FrozrWorld's fastest SSDs can start to lower performance when getting hot. Part of the motherboards heatsink design, the double side M.2 Shield Frozr is the next generation M.2 thermal solution to avoid this by offering the best thermal protection to make sure that SSD maintains maximum performance.
Aluminum BackplateThe heavy and aluminum backplate not only strengthens the motherboard, protects components, prevents PCB bending, but also cools down your Mosfet with dedicated thermal pad, makes your VRM temperature low and ensures even high-end CPU to run in full speed.
Frozr AI CoolingDetecting CPU & GPU temperatures and automatically adjusting fan duty of system fans to a proper value by adopting MSI AI ENGINE.Fully Controllable in BIOS and SoftwareMSI motherboards let you manage speeds and temperatures for all your system and CPU fans. Total Fan Control allows you check your primary system characteristics in a simplified graphical interface. You can also set up to 4 temperature targets for CPU and motherboard, which will adjust the fan speeds automatically.Autodetect Dc Or Pwm Mode With HysteresisMSI fan headers automatically detect fans running in DC or PWM mode for optimal tuning of fan speeds and silence. Hysteresis also makes your fans spin up fluently to make sure your system stays silent, no matter what.DIY 2.0 - Integrating With The System EnvironmentConnect and synchronize with MSI coolers and cases with strategically positioned pin-header locations including a dedicated pump-fan header.Optimized For Water CoolingDesigned to support the most popular All-In-One & customized water cooling solutions on the market. A dedicated water pump PIN header supports up to 3 amp, giving you full control of the water pump speed. A clearly marked 'keep-out-zone' allows for easy and safe installation and a perfect fit.
Power Solution Direct 19+2 Phases Power Design Unleash and sustain the maximum performance with a flagship VRM design built with a total of direct 19+2 digital power phases. Combining dual power connectors and 105A Smart Power Stage, MEG Z690 UNIFY-X is ready for the challenge of high-end processors.• Dual CPU Power Connectors• Direct Digital PWM• Optimized for Intel ProcessorsCore BoostCore Boost technology combines MSI's premium layout and digital power design which allows for faster and undistorted current delivery to the CPU at pin-point precision. Not only supporting multi-core CPU, also creating the perfect conditions for your CPU overclocking.1-Second Overclocking!MSI Game Boost enables one-second overclocking, giving you the performance boost you need to get more FPS.More For PerformanceLoad-Line CalibrationWhat you set, is what you get. LLC makes sure your CPU voltage remains 100% stable under any load. This greatly improves stability when demanding more CPU performance.Overvoltage ProtectionPrevents potential short-circuit damage to the CPU and other critical components.Digitall Power DesignA fully digital power design allows for faster and undistorted current delivery to the CPU at pin-point precision. Creating the perfect conditions for CPU overclocking.Double Power ConnectorsTwo 8-pin connectors deliver adequate power even for an overclocked multi-core CPU.DIY- FriendlyExclusive Diy AccessoryMEG Z690 UNIFY-X is designed for extreme power users. To improve the user experience, the DIY Stands Set provides you a new way to build your PC platform with ease, it even supports fan installation with different scenario. Furthermore, the Tuning Controller allows power users to fine-tune the complicated overclocking parameter with just one button in your hand.• Diy Stands Set• Tuning Controller
Pre-Installed Io ShieldFeaturing the pre-installed IO shield, makes your installation process easier and safer. The patent-pending design protect your IO ports and also prevent electrostatic discharge damage, makes your motherboard a strong gaming foundation.
Boot Up GuaranteedHaving trouble with updating the BIOS or somehow corrupted it? Don't worry! With System-Saver, use one of 3 easy to use options to successfully boot your system again.Clear CMOSRestore the BIOS to the default settings - helpful in 99% of the cases to successfully boot again.Flash BIOS ButtonFlash the BIOS with only a connected power supply by following a few steps. CPU and memory not required.Dual BIOSTwo physical BIOS chips allow a fallback to plan B.Keep Out ZoneMSI motherboards circuitry ensure the case standoff keep out zones are pure and clean, preventing any component contact or damage to the motherboard.Avoid Collision NotificationProtective paint is printed around each screw hole to prevent parts from being scratched.More User Friendly EnhancementsEZ M.2 ClipHave trouble turning screws? MSI innovative EZ M.2 clip assist you install an M.2 SSD quickly and effortlessly.EZ Front Panel CableThis cable takes care of the tedious part of the build process, makes motherboard front panel connections quickly and accurately.XL ClipThe enlarged PCI-E clip helps you swap or remove your devices easier. Keep the PCI-E slot stronger and safer.Smart ButtonOne button with multiple hardware control. Reset Computer, Safe Boot, Turbo Fan and EZ LED control functions with just one click.Debug LEDDisplays the error code for troubleshooting. Also functions as temperature monitor!ProtectionPCB DesignThe PCB design has been optimized for higher bandwidth and faster transfer speeds, which is also beneficial for reliable circuit transmission.• 8 PCB layers• IT-170 Server-grade PCB material• 2oz Thickened CopperFortify Your System With PCI-E Steel ArmorMSI PCI Express Steel Armor slots are secured to the motherboard wit
