Hantek DSO8060 5-in-1 Handheld Oscilloscope 60MHz DMM Spectrum Analyzer Frequency Counter Arbtrary Waveform Generator

Features : DSO8060 5-in-1 Handheld Oscilloscope: Oscilloscope DMM Spectrum Analyzer Frequency Counter Arbtrary Waveform generator High Bandwidth 60MHz Oscilloscope, and 6000 COUNTS high precision DMM. Seperated GND Reference. Hardware Frequency Counter. Arbitrary Waveform Generator: 25Mz arbitrary waveform output, (sine wave can deliver up to 75 Mz) 200 MSa/s DDS, 12 bits of vertical resolution. FFT + - * / ,X-Y, 22 kinds of auto measurements, PASS/FAIL Check, easy to use on production line. High refresh rate; High Real-time Sample Rate 150MSa/s-2GSa/s; 50GSa/s Equivalent-time Sample Rate. Multiform trigger mode, 2 separate time base in ALT trigger mode, easy to see 2 signal with different frequency. 1000 waveforms save and record. Excellent Industrial Design. Direct key for Each Channel, time base, Trigger and DMM, easy to operate. Large 5.7 inch TFT Color LCD Display, LED backlight, Display clearly. USB Host/Device 2.0 full-speed interface, support removeable disk, LAN Option; Easy to control by PC or long-distance. Battery Power Operation (Installed) Industrial Design. Save waveform in the following: jpg/bmp graphic file, MS excel/word file. Dimensions (mm):240(L)x165(W)x50(H) be carried easily. LabviewVBVC Second Design instance. Specification : Model DSO8060 Bandwidth 60MHz Channel 2 Real-Sample Rate 250MSa/s Equivalent Sample Rate 50GSa/s Record Length 32K Rish time 5.8ns Timebase Accuracy 50ppm Time Base Range 5ns/div-1000s/div Video Help -- SD Card -- Input Impandance 1M 15pF VOLTS/DIV Range 10mV/div-5V/div A/D Converter 8bit Position Range 50V(5V/div) 40V(2V/div-500mV/div) 2V(200mV/div-50mV/div) 400mV(20mV/div-2mV/div) DC Gain Accuracy 3% for Normal or Average acquisition mode, 5V/div to 10mV/div; 4% for Normal or Average acquisition mode, 5mV/div to 2mV/div Bandwidth Limit 20MHz Trigger Types Edge, Video, Pulse, Alternative Trigger Source CH1, CH2 Math +,-,x,,FFT, Invert Cursor Measurement Voltage difference between cursors: V; Time difference between cursors: T; Reciprocal of T in Hertz (1/T); Auto Measuerment Frequency, Period, Mean, Pk-Pk, Cycli RMS, Minimum, Maximum, Rise time, Fall Time, +Pulse Width, -Pulse Width, Delay1-2Rise, Delay1-2Fall, +Duty, -Duty, Vbase, Vtop, Vmid, Vamp, Overshoot, Preshoot, Preiod Mean, Preiod RMS, FOVShoot, RPREShoot Waveform Frequency DC~25MHz DAC Clock 2K~200MHz adjustable Frequency Resolution 0.10% Channel count 1CH waveform output Waveform Depth 4KSa Vertical Resolution 12 bit Frequency Stability 100K DMM Max. Resolution 6,000 Counts Testing Modes Voltage, Current, Resistance, Capacitance, Diode & Continuity Max. Input Voltage AC: 600V, DC: 800V Max. Input Current AC: 10A, DC: 10A Max. Input Impandance 10M Display 5.7" TFT Display, 320*240 dots Size 245mm x 163mm x 52mm Weight 1.3KG(Without Package) Standard Probe PP80x2 DMM Mode Max. Resolution 6000 Counts DMM Testing Modes Voltage, Current, Resistance, Capacitance, Diode & Continuity Max. Input Voltage AC:600V, DC: 800V Max. Input Current AC: 10A, DC:10A Input Impedance 10M DMM TrendPlot 1.2M Point Range Resolution Accuracy Resolution DC Voltage 60.00mV 1%3 digit 10uV 600.0mV 100uV 6.000V 1mV 60.00V 10mV 600.0V 100mV 800V 1V AC Voltage 60.00mV 1%3 digit 10uV 600.0mV 100uV 6.000V 1mV 60.00V 10mV 600.0V 100mV DC Current 60.00mA 1%5 digit 10uA 600.0mA 1.5%5 digit 100uA 6.000A 1mA 10.00A 10mA AC Current 60.00mA 1%5 digit 10uA 600.0mA 1.5%5 digit 100uA 6.000A 1mA 10.00A 10mA Resistance 600 1%3 digit 0.1 6.000K 1 60.00K 10 600.0K 1K 6.000M 10K 60.00M 1%5 digit 100K Capacitance 40.00nF 2%5 digit 10pF 400.0nF 100pF 4.000uF 1nF 40.00uF 10nF 400.0uF 100nF Attention: the smallest capacitance value that can be measured in 5nF Diode 0V~2.0V ON-OFF test
