iFlight BLITZ PSM BXN 5D2UD6 BEC Module 5V 12V Output for RC Drone FPV Racing

Introduction The BLITZ ESC features step down switch mode high efficiency synchronous rectification and the ability to step down from an input voltage of up to 35V to a low output stable voltage which makes it ideal for step down voltage applications It offers a very compact solution to achieve 2A 3A output current over a wide input supply voltage 6 to 35V Short connect ON 12V the output voltage is 12V When disconnected the output voltage is 5V Features Step down switch mode High efficiency synchronous Wide 6V to 35V Input voltage range The voltage output can be 5V or 12V adjustable default 5V Specification Input voltage 6 35VOutput voltage current 5V or 12V Average 2A Peak 3AConversion efficiency the average efficiency of output 12V is above 92 and the average efficiency of output 5V is above 88 Size 12x14x4 5mmPins distance 2 55mmWeight 1 8gNotice If there is sparking phenomenon when the power is turned on it is recommended that the input voltage should not exceed 26V Package Included 1x BEC Module1x Connection Cable
