Zerodis Breadboard Kit Test Board QC2.0 / QC3.0 Fast Charge Adapter Mobile Power Detection Module With Dial Switch Test Board

Feature: 1. Uses intelligent detection QC2.0/QC3.0 protocol to select output voltage and the voltage is stable output. 2. Has a wide range of compatibility fully supports QC2.0‑QC3.0 charger QC2.0‑QC3.0 mobile power supply and other products. 3. The operation is simple and easy to use. You can select a fixed output voltage testing by flipping the switch and the corresponding LED lights are on. 4. Adopts sophisticated production technology this test board has excellent performance and accurate test data. 5. Made of high‑quality materials this test board is sturdy durable will not disconnect during use and has a long service life. Specification: Item Type: Test Board Material: Resin Model: None Output Voltage: 3.6-12V Applicable Protocol: QC2.0/QC3.0 Products Used: Chargers Mobile Power Supplies Product Size: Approx. 66 x 16 x 12mm / 2.6 x 0.6 x 0.5in (Including Dual USB) Use: Set by Dial Switch to Make the Adapter Output the Corresponding Fixed Voltage Package List: 1 x Test Board Note: Before use please confirm whether the output voltage matches the demand voltage of the load so as to avoid unnecessary losses caused by the burning of the load. How to use: Through 8 different combinations of dial switches it is decided to output 8 different voltages. 1. When the dial switch is set to the top it means 0 and when the dial switch is set to the bottom it means 1 . 2. The switch is at the position of 001 which means the output protocol is QC2.0 the output voltage is 5V and the green light is on. 3. The switch is at the position of 010 which means the output protocol is QC2.0 the output voltage is 9V and the red light is on. 4. The switch is at the position of 100 which means that the output protocol is QC2.0 the output voltage is 12V and the blue light is on. 5. The switch is at the position of 000 which means that the output protocol is QC3.0 and the output voltage is 3.6V. Remember that when entering the QC3.0 protocol the USB female socket must carry a 0.5A load to work normally otherwise 3.6V will Automatic protection. 6. The switch is at the position of 011 which represents the protocol of output QC3.0 the output voltage is 5V and the green light is on. 7. The switch is at position 101 which represents the pro
