ZXY6010S NC DC-DC Power Supply Module 60V 10A 600W Programmable

ZXY6010S NC DC-DC Power Supply Module 60V 10A 600W Programmable Constant Voltage Current Introduction: ZXY-6010S is single output programmable switch power supply. Its specification is 60V, 10A, 600W. It designed by DC-DC modularization ,has a small size and a high output power. Besides, it has equipped with TTL serial interface, provide a serial communication protocol, allows user to secondary development, we can according to your design and test requirements to provide versatile solutions. Main special features and advantages: Based on BUCK structure of switch power supply technology, the work frequency reach up to 150 KHz DC input voltage range : DC 13V-62V, which is suitable for multiple kinds of pre-stage input power supplies Operation key and multi-function encoder combine for the operation, it is convenient and easy to use High accuracy and high resolution: 10 mV / 10 mA Low ripple and low noise Indicator light: Constant current(CC) ,constant voltage (CV) and output state (ON) indicator LCD1602 display Adjust voltage and current by adjustment knob and keys Support measuring and displaying output voltage, output current, output power, output electric quantity (AH) and working time Intelligent temperature detection, can connect an external DC12V fan, and control its speed in level 5 The minimum voltage difference 2V can still work steadily With output turn off function key, flexible turn on or off output 10 groups of parameter settings of M0-M9, which can be conveniently called out at any moment Prompt for operation or alarm function of onboard buzzer Convenient and simple three-phase charge intelligent control function of storage battery With TTL serial communication, and improved communication protocol so as to be convenient for centralized control Parameter: Input voltage: 13V - 62V Output voltage: 0-60V Output current: 0-10A Output power: 0-600W Setup resolution of output voltage: 10mV Setup resolution of output current: 10mA Source regulation: CV is less than 0.5% + 10 mV CC is less than 1% + 5 mA Load regulation: CV is less than 0.5% + 10 mV CC is less than 1% + 5 mA Output ripple: / M button, P5: SEL button, P6: OUT / OK button. J6: On the top small box from top to bottom P1: P1 pin encoder, P2: encoder com, P3: P3 pin encoder. J3: The right of the small box from right to left P1: OUT + P2: OUT- when the power output leads to use, when using need to OFF JUMP1, JUMP2 short point. J2: On the left of small box from left to right P1: CV + P2: CV- P3: CC + P4: CC- P5: OUT + P6: OUT-. OUT indicator which corresponds to the resistance R25, R27 corresponding CV indicator, R28 corresponding CC indicator, if you want to change the resistance of these three sizes, adjust the brightness of the external lights. More details: Please click here to download. Package included: 1 x ZXY6010S power module 1 x ZXY6010S control module 1 x 6P cable 2 x large current connect line
