YYS-1 Programmable 4 Channel LED Relay Module Signal Trigger Delay Timer Relay PLC Controller

Specification Working voltage DC 5 12 24V Optional Output capacity DC 30V AC 220V Current 10AStatic current 20mAWorking current of single relay 30mASignal type Active lowSize 92 3 x 87 3 x 18 5mmHole diameter 4mm 0 16inHole pitch 85 x 80mm Module Interface DC Connected to power supply positiveDC Connected to power supply negativeIN Can control the relay to pull in at a low level Relay Output Ports NO Relay normally open interfaceCOM Relay common interfaceNC Relay normally closed interface Default Functions 1 Give a low level signal to IN1 relay 1 pulls in After X1 seconds delay relay 1 releases 2 Give a low level signal to IN2 relay 2 pulls in After X2 seconds delay relay 2 releases 3 Give a low level signal to IN3 relay 3 pulls in After X3 seconds delay relay 3 releases 4 Give a low level signal to IN4 relay 4 pulls in After X4 seconds delay relay 4 release 5 Give a low level signal to IN5 all relays 1 2 3 4 pull in 6 Give a low level signal to IN6 all relays 1 2 3 4 release The signals to IN1 IN2 IN3 and IN4 are interlocked and each time a signal is given the other signals are not valid until the relay completes the action The signals to IN5 and IN6 are timely signals and are not subject to any constraints In any state IN5 and IN6 can be effectively executed Package Included 1 x YYS 1 Programmable 4 Channel LED Relay Module
