YIHAOGD YH 2/3 Axis Grating CNC Milling Digital Readout Display DRO / TTL 50-1100mm Electronic Linear Scale Encoders Lat

Description YIHAOGD YH 2 3 Axis Grating CNC Milling Digital Readout Display 5μ 50 1000mm TTL Electronic Linear Scale Lathe Tool Specification Dro Digital Readout Display System ParameterModel 2 Axis 3 AxisVoltage Range AC 100V 240V 50HZ 60HZDigital Readout Display Acceptable Signal TTLPlug DB9Acceptable resolution 10μm 5μm 2μm 1μm 0 5μm Size The optional length is measuring effective lengthTotal length measuring effective length 142mmDro Digital Readout Display System Functions1 Zero clearing2 Reset3 mm inch mode4 ABS INC coordinate conversion5 200sets sub datum6 Power off Memory 7 Center of 1 28 Liner error compensation9 Sleepping mode10 Clear 200 sets Sdm datum 11 ABS INC mode12 Calculator13 Drilling of circumference14 Drilling of oblique line15 Machining of inclined plane16 Machining of circular arc17 Lathe function match 18 Rectangular lumen gradual processing19 Digital filtering20 Vibration filtering21 R Diameter fucntion22 Lathe function5U TTL Linear Scals Linear Encoder Linear Sensor Linear Ruler Parameters1 Travel measuring length 0 1000mm 0 40inch2 Total overall length Travel length 142mm 0 1142mm 3 Plug DB94 Resolution 0 005mm 5μ 5 Input voltage 5V6 Grating pitch 0 02mm 50LP min 7 Cable length 3 Meter8 Normal size About 22 349 Protection class IP5410 Signal TTLThe Signal of 5μ Linear Optical Ruler Linear Glass Scales Linear Encoder Linear SensorPin 2 Black 0VPin 6 Green APin 7 Red 5VPin 8 White BPin 9 Orange ZFeatures Wh
