XY-LJ02 DC 6-30V Micro USB Digital LCD Display Time Delay Relay Module Control Timer Switch Trigger Cycle Module

Description Timing Range 0 01 sec 9999 minThis product LCD display very clear simple and easy to use powerful but please read user instructions carefully before using Features 1 Display with LCD two columns Can display parameters directly 2 Trigger mode high and low level switch quantity meet most of the needs 3 Power supply 6 30V also supports micro USB 5 0V very convenient Anti back connection of power supply 4 Parameters can be modified via UART 5 Stop button to provide emergency stop function 6 5 minutes without any operation into a low power state Any action wake up 7 OP CL LOP params can be modified individually8 All parameters are automatically saved by power off Product Parameters 1 Power Supply 6V 30V and micro USB 5 0 V2 Trigger signal source High level 3 0V 24 0V Low level 0 0V 0 2V Switch signal 3 Maxmum Output load DC 30V 5A and AC 220V 5A 4 Static Current 15mA Operating current 50mA 5 Service life more than 100 000 times working temperature 40 85°C size 8 0 3 8 1 9cm 6 Optocoupler isolation Strong anti interference ability Industrial grade circuit boardPackage included 1 X Delay Relay ModuleWorking Mode Introduction P1 P7 P1 After the signal is triggered the relay conduction in OP time then disconnects In the OP time the signal is invalid P2 After the signal is triggered the relay conduction in OP time then disconnects In the OP time the signal triggers a new timer P3 After the signal is triggered the relay co
