XY-L10A 6-60v 10A Lead-acid Solar Storage Battery Charge Controller Module Protection Board charger Time Switch Battery

Module Highlights Support Lead acid battery and Acting Battery voltage range 6V 60VCan display voltage percent of battery charging time at the same time through LCD The function is very powerful realizes the automatic charge control the control charge time also may set up and uploads the corresponding parameter through the serial port Function description 1 Automatic Charge control function By setting the volt HI UP volt LI dn When the battery voltage is below the volt LI dn the relay leads the charger begins to charge the battery when the battery voltage is up to volt HI UP the relay is diconnected and the automatic charge is completed once 2 Charge Time Control Function How to turn on the time control function After entering the parameter set set the parameter op is non zero then turn on the time control function op default parameter is h the default does not turn on time control function After the opening Time control function OP is non zero when the battery voltage is the lower volt LIdn the charger began to charge the battery the system began to clock During the timing the battery voltagevolt HIUP relay disconnect If the OP time is up the battery voltage is still the lower volt LIdn the relay keeps the conduction automatically closes the charge time control function and flashes the H ER to remind the user the time parameter setting is unreasonable Press any key to stop flashing Note Time format 00 59 00 for hours 59 for minutes
