XY-J04 DC 5V-36V Trigger Cycle Timer Delay Switch Circuit Double MOS Tube Control Board

Features: 1. 30V version: Wide voltage operation (5~36V) most devices can be used, very convenient; 2. The interface is clear and simple, powerful, easy to understand, and almost meets all your needs; 3. One button emergency stop function (STOP button) with reverse connection protection, reverse connection does not burn; 4. Added sleep mode. After enabling, there is no operation within 5 minutes, the display is automatically turned off; any button wakes up; 5. Different OP, CL, LOP parameters can be set, these parameters are independent of each other and saved separately; 6. With optocoupler isolation, enhance anti-interference ability, industrial grade circuit board, set parameters forever after memory Specifications: - Operating voltage: DC 5V--36V - Trigger signal source: High-level trigger (DC 3.0V24V) signal ground and system ground to improve the anti-interference ability of the system (also can be short-circuited by itself) - Output capacity: DC 5V--36V (Continuous current 15A at normal temperature, power 400W. Under the condition of auxiliary heat dissipation, the maximum current can reach 30A.) - Quiescent current: 15mA - Timing range: 0.1 second (minimum) ~ 999 minutes (maximum) continuously adjustable - Operating temperature: -40-85 C - Size: 6.0*3.4*1.2cm XY-J04 Usage(Please Click Here) Applications: 1. Realize high frequency, fast and frequent switching of the circuit, unlimited number of switching times; 2. There will be no noise during the on/off process, no sparks, no electromagnetic interference; 3. The service life is longer than that of common electromagnetic relays; 4. Double MOS parallel active output, lower internal resistance, larger current, strong power, 15A, 400W at normal temperature, meeting the needs of most equipment; 5. It is often used to control motors, bulbs, LED strips, DC motors, micro pumps, solenoid valves, etc. With this module, these devices can be easily controlled, which is very convenient. Note: 1. The module is an active live output, and the output (load) voltage is equal to the input voltage of 30V (DC 5V--36V); 40V version (DC-5-40V). 2. 'DC+' and load '+' are themselves short-circuited internally, but 'DC-' and load '-' poles cannot be short-circuited during use, otherwise the load will not be controlled to be turned on and off, equivalent to The load is always on. Package Included: 1 x XY-J04 DC 5V-36V Trigger Cycle Timer Delay Switch
