XR2206 High Precision Signal Generator Adjustable Frequency Amplitude Kit, 501 Original

XR2206 High Precision Function Signal Generator DIY Kit Sine/Triangle/Square Output 1Hz-1MHz Adjustable Frequency AmplitudeFeatures:1. High resolution, can generate sine/triangle/square waveforms.2. Frequency range: 1Hz-1MHz.Adjustable frequency and amplitude.3. Five bit precision resolution.4. Frequency adjustment features coarse tuning and fine tuning.5. Wide power supply range, use 9-12V external power or 9V battery(NOT Included).6. All are through hole components, easy for installation.Specification:Model: XR2206Type: A(spare parts)Frequency: 1HZ-1MHZ (MHz)Level: 9-12 (V)Size: about 60*45*20 mm/2.36*1.77*0.78\\'\\'Power supply voltage: 9-12V DC inputWaveforms: square, sine and triangleImpedance: 600 ohm + 10%Sine Wave:Amplitude: input 0-3V in 9V DCDistortion: less than 1% (1kHz)Flatness: + 0.05db 1Hz extensionSquare Wave:Amplitude: 8V (no-load) input in 9V DCRising time: less than 50ns (1kHz)Down time: less than 30ns (1kHz)Symmetry: less than 5% (1kHz)Triangle Wave:Amplitude: input 0-3V in 9V DCLinearity: less than 1% (up to 100kHz) 10mANote:Please allow 1-3mm differs due to manual measurement.Due to the different display and different light, the picture may not show the actual color of the item. Thanks for your understanding.Package Content:1 x Set Signal Generator DIY Kit1 x User Manual
