XKC-C360-3P 3M High and Low Liquid Level Controller with 3 Non Contact Sensor Module Automatic Control Fluid Water Posit

Manual Click here to openOverview XKC C360 3P high and low level controller and XKC Y26 V three liquid level detection heads realize liquid level high and low control and motor idling protection function when the container liquid level is too low it will trigger the low liquid level alarm signal sent by the low liquid level sensor Trigger the C360 controller to close the relay to start the water pump to add liquid level When the liquid level reaches a certain height the high liquid level sensor sends a signal to trigger the C360 controller to open the relay and automatically stop the water pump Thereby the function of automatic control of the container liquid level is realized and the container liquid level is kept stable The idling protection function of the water pump is also added When there is no water at the water inlet the water pump will be automatically disconnected for 3 5 minutes to protect the water pump Features 1 AC95 265V wide voltage power supply2 Relay dry node output suitable for multiple load control3 The control is diversified and the pump can be controlled in manual or automatic mode4 The installation is simple and convenient It can be installed with screws or electric box tracks Electrical parameters Model XKC C360 3PName C360 high and low liquid level automatic controllerInput voltage AC100V 220V 50 60HzWorking voltage DC12VWorking current working current ≤110 mA static current consumption ≤20mALoad power below 1 6KW for overlo
