XD9800 300Mbps 802.11n Ceiling Mount Access Point

The XD9800 Series is a PoE Ceiling Mount Access Point (AP) that using concurrent 2.4 GHz and featuring the advanced 802.11n technology. The smoke detector look exterior makes the XD9800 Series perfect for indoor ceiling-mount installation; with the optimized antennas built-in, its design solves the common interference issue in ceiling-mount deployments. The AP supports multiple operating modes, such as AP, Gateway and repeater, which make it an ideal, flexible solution for small business, hotels and school environments.
Features
Compact ceiling-mount design with optimized RF performance.
600Mhz MTK7620A RF Chipset, 802.11b/g/n Support.
128MB SDRAM + 16MB Flash Build-in for Higher Performance.
Gateway / Repeater / AP operation modes.
IEEE 802.3af or Passive 24V PoE supports up to 60 meter (180 feet) deployment.
Central AP Control Management Software Support.
Specifications
Wireless
Standards
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Data Rate
300Mbps
Frequency Band
2.4~2.4835GHz
Wireless Transmit Power
11n MCS7:26±1dBm 11g 54Mbps:26±1dBm 11b 11Mbps:27±1dBm
Receive Sensitivity
11N MCS0@-83dBm ; MCS7@-65dBm 11G 54Mbps@-82dBm ; 6Mbps@-95dBm 11B 11Mbps@-85dBm ; 1Mbps@-95dBm
Operation Mode
Gateway, Repeater(Extender), AP(access point)
Wireless Security
64/128-bit WEP, WPA/WPA2, WPA /WPA2-Personal (TKIP/AES)
System Requirements
Windows 7/Vista/XP/2000,Mac OS®, Linux or Android OS, IOS
Hardware
Interfaces
2 x RJ-45 for 10/100 Mbps(POE), 1 x Power DC Jack
MCU
MTK7620A
SDRAM&FLASH
128MB+16MB
Button
1 x Reset button(Reset & Factory Defaults)
LED Indicator
WiFi, Power, System
Antenna
2x built-in 3dBi omni-directional Antenna
Power Supply
IEEE 802.3AF or POE 24V/12V1A;110V/220V
Software
Wireless Function
Distance Control (802.1x Ack timeout), Multiple SSID (4 SSID)
Security
WEP Encryption-64/128/152 bitWPA/WPA2 Personal (WPA-PSK using TKIP or AES) WPA/WPA2 Enterprise (WPA-EAP using TKIP) Hide SSID MAC/IP Address &URL filtering Wireless STA (Client) connected list
DHCP
DHCP Server, DHCP Client
Network
Port Mapping, DMZ Host, Statics Routing, DDNS,UPNP
Management
Firmware Upgrade and backup, factory Reset, Restart, WEB management, log management, the PING tool
Product Size
16.5 x 16.5 x 4.5 cm
Product Weight
400g
Package Size
31 x 20 x 6 cm
Package Weight
650g
