XD9410 300Mbps 802.11n Ceiling Mount Access Point

The LAFALINK XD9410 Series is a PoE Ceiling Mount Access Point (AP) that using concurrent 2.4 GHz and featuring the advanced 802.11n technology. The smoke detector look exterior makes the XD9410 Series perfect for indoor ceiling-mount installation; with the optimized antennas built-in, its design solves the common interference issue in ceiling-mount deployments. The AP supports multiple operating modes, such as AP, Gateway and repeater, which make it an ideal, flexible solution for small business, hotels and school environments.
Features
Compact ceiling-mount design with optimized RF performance.
600Mhz MTK7620N RF Chipset, 802.11b/g/n Support.
64MB SDRAM + 8MB Flash Build-in for Higher Performance.
Gateway / Repeater / AP operation modes.
IEEE802.3af 48V PoE supports up to 70 meter (200 feet) deployment.
Central AP Control Management Software Support.
Specifications
Wireless
Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Data Rate 300Mbps
Frequency Band 2.4~2.4835GHz
Wireless Transmit Power 11n MCS7:26±1dBm, 11g 54Mbps:26±1dBm, 11b 11Mbps:27±1dBm
Receive Sensitivity 11N MCS0@-83dBm ; MCS7@-65dBm, 11G 54Mbps@-82dBm ; 6Mbps@-95dBm, 11B 11Mbps@-85dBm ; 1Mbps@-95dBm
Operation Mode Gateway, Repeater(Extender), AP(access point)
Wireless Security 64/128-bit WEP, WPA/WPA2, WPA /WPA2-Personal (TKIP/AES)
System Requirements Windows 7/Vista/XP/2000,Mac OS®, Linux or Android OS, IOS
Hardware
Interfaces 1 x RJ-45 for 10/100 Mbps(POE), 1 x Power DC Jack
MCU MTK7620N
SDRAM&FLASH 64MB+8MB
Button 1 x Reset button(Reset & Factory Defaults)
LED Indicator WiFi, Power, System
Antenna 2x built-in 3dBi omni-directional Antenna
Power Supply POE IEEE802.3af 48V/12V1A;110V/220V
Software
Wireless Function Distance Control (802.1x Ack timeout), Multiple SSID (4 SSID)
Security WEP Encryption-64/128/152 bit, WPA/WPA2 Personal (WPA-PSK using TKIP or AES), WPA/WPA2 Enterprise (WPA-EAP using TKIP), Hide SSID, MAC/IP Address &URL filtering, Wireless STA (Client) connected list
DHCP DHCP Server, DHCP Client
Network Port Mapping, DMZ Host, Statics Routing, DDNS,UPNP
Management Firmware Upgrade and backup, factory Reset, Restart, WEB management, log management, the PING tool
Product Size 16.5 x 16.5 x 4.5 cm
Product Weight 400g
Package Size 31 x 20 x 6 cm
Package Weight 650g
