Worm Gear Motor Turbo Geared Full Metal Self Locking Reduction Gearbox JGY‑370 DC24V66RPM
Описание
Item Type: Worm Gear Motor Model: JGY-370 Material: Carbon zinc alloy stainless steel Purpose: Drive device Whether to Adjust the Speed: Yes Whether CW and CCW: Yes Operating Voltage: DC 24V Output Shaft Size: Approx. 8mm / 0.3in output shaft M5 threaded rod double flat position Reduction ratio (change ratio) 40 65 90 150 200 260 340 600 1000 No load current MA≤60 ≤60 ≤60 ≤60 ≤60 ≤60 ≤60 ≤60 ≤60 No load speed rpm 150 90 66 40 30 23 18 10 6 Rated torsion kg.cm 0.2 0.5 0.7 2 5.3 6.7 9 15.9 26.5 Rated speed rpm 120 70 51 30 22 18 15 7.5 4 Rated current A ≤0.3 ≤0.3 ≤0.3 ≤0.3 ≤0.3 ≤0.3 ≤0.3 ≤0.3 ≤0.3 Maximum torsion Kg.cm 0.9 1.6 2 7.5 10 13 18 30 45 Stop current A 0.85 0.85 0.85 0.85 0.85 0.85 0.85 0.85 0.85
