Wireless Remote Control Switch 10A Mini Relay Receiver

Suitable for security alarm, remote control electric doors and windows, signal control and etc. Easy to install and use. Save yourself time by using a wireless remote to switch on your load from a distance.
Features
Strong signal controls receiver from any place within a reliable distance.
Eliminate the trouble of messy wiring and time consuming work.
It covers application ranging from like auto door, window, lifting equipment, entrance access, etc.
Two working frequency : 315MHZ/433MZH optional.
Three output way : Momentary. Toggle. Latched Adjusted by Jumper.
Working Way
A: Momentary-----------Put the Jumper on "M&G"
B: Toggle------------put the Jumper on "T&G"
C: Latched------------- Take way the Jumper or put the Jumper on any 1 Pin.
Code type: Learning code add controller by the learning button on the receiver.
Output state is adjusted by the jumper on the receiver board.
Learning Method: Press the Learning Button until the Led indicator ON. Then press transmitter, the Led indicator flash fast, it mean learning successfully.
Clearing Code: Keeping press the Learning Button on the receiver until the LED indicator OFF, it mean the code have been cleared successfully.
Specifications
Operating Voltage DC6V
Operating Current 30MA
Operating Frequency 315/433MHz
Working Voltage AC220V +- 10%
Max Load10A Relay
Resistive Load ≤8A
Inductive Load ≤3A
Channel 1CH
Receiver Sensitivity : -105Db
Working Temperature -10'C - +60'C
Frequency Distance 20M-200M
Package Size 55 x 32 x 17 mm
Package Contents 1 x Receiver(Without cover) 2 x Transmitters(With batteries)
