(Wifi Car Dedicated) NodeMcu Lua ESP8266 ESP-12E + WiFi Motor Drive Expansion Board

Wifi Car Dedicated NodeMcu Lua ESP8266 ESP 12E WiFi Motor Drive Expansion BoardNote This NodeMcu Lua module is dedicated to the wifi smart car which means this module have the special program for the wifi smart carSoftware http bbs smart com showthread php tid 2043pid 2213 pid2213Feature ESP12 DEV KIT development board expansion module ESP12 DEV KIT leads all function pins SPI UART GPIO AI and 3 3V power connector Expand two way motor driven two way direct drive motor Onboard power switch Motor Power range 4 5V 36V Control power range 4 5V 9V Motor power control power separation In the experiment by short circuiting block the merger the VIN and VM short while power supply to the motor and the control board Note When you insert ESP 12E module please note the direction consistent with the expansion board antenna The use of Short circuit module that can simultaneously control board and the electrical power supplyPackage included 1 x Wifi Car Dedicated NodeMcu Lua ESP8266 ESP 12E1 x WiFi Motor Drive Expansion Board
