Wide Dynamic 1080P HD USB Camera Module Support H264 YUV2 YUYV MJPEG Face Recognition Backlight Monitoring 2048X1536

Note: This camera is suitable for face recognition. It does not have an identification function itself, and the recognition function needs to be developed by the customer. This product has been widely used in face recognition, human witness comparison, ATM machines, security gates, airport security, edge inspection gates, etc. Features: USB camera with wide dynamic effect, using high-quality photo sensor of AR0331, the dynamic range is up to 100dB, suitable for backlight shooting, 3 million pixels, H.264 video format output. Product number RER-USB3MP01H-LS29 Sensor AR0331 Lens Size 1/3 inch Cell size 2.2um X 2.2um Effective Pixels 2048(H)X1536(V) Output image format H264 YUV2 (YUYV) MJPEG Frame rate 1920*1080 @ 30fps H264/MJPEG Signal to noise ratio 39dB Dynamic Range 100dB Sensitivity 1.9V/lux-sec@550nm Shutter type Electronic rolling shutter / Frame exposure Interface Type USB2.0 High Speed Support for the drive-free protocol USB Video Class (UVC) Support OTG protocol USB2.0 OTG Automatic exposure control AEC Support Automatic white balance AEB Support Automatic gain control AGC Support Adjustable parameter Brightness contrast color saturation tone definition Gamma gain white balance backlight contrast exposure H264 format adjustable parameters Bit rate Compression ratio Programmable OSD menu Support Supported resolution H264: 640X360 1280X720 1920X1080 MJPEG: 640X480 800X600 1280X720 1280X1024 1600X1200 1920X1080 2048X1536 YUV: 640X480 800X600 1280X720 1280X1024 1600X1200 1920X1080 2048X1536 Digital audio High quality digital MIC, optional single and dual channel IRCUT interface Support 2P-1.25mm socket Infrared light board power supply interface Support 2P-2.0mm socket Power supply USB BUS POWER 4P-2.0mm socket Operating Voltage DC5V Working current 200mA~350mA Operating temperature 0 to 60 C storage temperature -20 to 70 C Board size 38X38mm Board weight 30g Supported system Win7 Win8 (providing SDK) Linux 2.6 or above (providing SDK) Android 4.0 or above Package includes: 1 x Camera Module 1 x Cable
