Waveshare Motor Driver HAT for Raspberry Pi Zero/Zero W/Zero WH/2B/3B/3B+, I2C Interface,Onboard PCA9685 chip
![Waveshare Motor Driver HAT for Raspberry Pi Zero/Zero W/Zero WH/2B/3B/3B+, I2C Interface,Onboard PCA9685 chip](//ae04.alicdn.com/kf/HTB1wLwYXe6sK1RjSsrbq6xbDXXa0.jpg)
![thumb](//ae04.alicdn.com/kf/HTB1wLwYXe6sK1RjSsrbq6xbDXXa0.jpg)
![thumb](//ae04.alicdn.com/kf/HTB1I4M1gwHqK1RjSZFgq6y7JXXap.jpg)
![thumb](//ae04.alicdn.com/kf/HTB16lcZXcfrK1Rjy0Fmq6xhEXXa0.jpg)
![thumb](//ae04.alicdn.com/kf/HTB1nU.2gAvoK1RjSZFwq6AiCFXaY.jpg)
![Waveshare Motor Driver HAT for Raspberry Pi Zero/Zero W/Zero WH/2B/3B/3B+, I2C Interface,Onboard PCA9685 chip](http://ae04.alicdn.com/kf/HTB1wLwYXe6sK1RjSsrbq6xbDXXa0.jpg)
![thumb](http://ae04.alicdn.com/kf/HTB1wLwYXe6sK1RjSsrbq6xbDXXa0.jpg)
![thumb](http://ae04.alicdn.com/kf/HTB1I4M1gwHqK1RjSZFgq6y7JXXap.jpg)
![thumb](http://ae04.alicdn.com/kf/HTB16lcZXcfrK1Rjy0Fmq6xhEXXa0.jpg)
![thumb](http://ae04.alicdn.com/kf/HTB1nU.2gAvoK1RjSZFwq6AiCFXaY.jpg)
![thumb](http://ae04.alicdn.com/kf/HTB11iQ0XdfvK1RjSszhq6AcGFXaZ.jpg)
sku: 32945862802
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$15.83
Shipping from: China
Technical Details
Brand Name: | Waveshare |
Demo Board Type: | ARM |
Dimension: | 65mm x 30mm |
Logic Voltage: | 3.3V |
Model Number: | Motor Driver HAT |
Motor driver: | TB6612FNG |
Mounting hole size: | 3.0mm |
Onboard PCA9685 chip: | provides 12-bit hardware PWM to adjust motor speed |
Power Supply: | 6V~12V (VIN terminal) |
PWM driver: | PCA9685 |
Raspberry Pi connectivity: | compatible with Raspberry Pi Zero/Zero W/Zero WH/2B/3B/3B+ |
Reserved I2C control pins: | allows to work with other control boards |
