Waveshare® 2.7 Inch Ink Screen Bare Screen e-Paper Display Module 264x176 Resolution 2.7inch E-Ink Raw Display Three-col

Waveshare® 2.7 Inch Ink Screen Bare Screen e-Paper Display Module 264x176 Resolution 2.7inch E-Ink Raw Display Three-col
Waveshare
sku: 1754365
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$10.99
Shipping from: China
   Description
Documents:Manual: Click here to openSchematic: Click here to openDatasheet: Click here to openOverview:This is an E-Ink raw display, 2.7inch, 264x176 resolution, with embedded controller, communicating via SPI interface, supports red, black, and white three-color display.Due to the advantages like ultra low power consumption, wide viewing angle, clear display without electricity, it is an ideal choice for applications such as shelf label, industrial instrument, and so on.Features:No backlight, keeps displaying last content for a long time even when power downUltra low power consumption, basically power is only required for refreshingComes with development resources and manual (driver board schematic, examples for Raspberry Pi/Jetson Nano/Arduino/STM32)Specifications:Operating voltage: 3.3VInterface: 3-wire SPI, 4-wire SPIOutline dimension: 70.42mm × 45.8mm × 0.98mmDisplay size: 57.288mm × 38.192mmDot pitch: 0.217 × 0.217Resolution: 264 × 176Display color: red, black, whiteGrey level: 2Full refresh time: 15sRefresh power: 26.4mW(typ.)Standby power: 0.017mWViewing angle: 170°Package includes:1 x E-Ink raw display
