WaveShare DIY Raspberry 3B+ AlphaBot2 Smart RC Robot Car Tracking Avoidance Infrared bluetooth Control With Camera

WaveShare DIY Raspberry 3B+ AlphaBot2 Smart RC Robot Car Tracking Avoidance Infrared bluetooth Control With Camera
Eachine1
sku: 1428682
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$174.99
Shipping from: China
   Description
Description: Brand: Waveshare Product: RC Robot Car Raspberry Pi 3 Model B+ Specifications: - Broadcom BCM2837B0, Cortex-A53 (ARMv8) 64-bit SoC @ 1.4GHz - 1GB LPDDR2 SDRAM - 2.4GHz and 5GHz IEEE 802.11.b/g/n/ac wireless LAN, bluetooth 4.2, BLE - Gigabit Ethernet over USB 2.0 (maximum throughput 300 Mbps) - Extended 40-pin GPIO header - Full-size HDMI - 4 USB 2.0 ports - CSI camera port for connecting a Raspberry Pi camera - DSI display port for connecting a Raspberry Pi touchscreen display - 4-pole stereo output and composite video port - Micro SD port for loading your operating system and storing data - 5V/2.5A DC power input - Power-over-Ethernet (PoE) support (requires separate PoE HAT) AlphaBot2 Features: AlphaBot2-Base, the lower base chassis: - 5-ch infrared sensor, analog output, combined with PID algorithm, stable line tracking - Onboard modules like line tracking, obstacle avoiding, needs no messy wiring - TB6612FNG dual H-bridge motor driver, compared with L298P, it's more efficient, more compact, - and less heating - N20 micro gear motor, with metal gears, low noise, high accuracy - Onboard RGB LEDs, true color lighting, pretty cool AlphaBot2-Pi, the upper adapter board for controller: - LM2596 voltage regulator, provides the Pi with stable 5V power - TLC1543 AD acquisition chip, allows the Pi to use analog sensors - PCA9685 servo controller, make it more smoothly to rotate the pan head - CP2102 UART converter, easy for controlling the Pi via UART Note: photos are FOR REFERENCE ONLY, the other boards/modules/accessories are NOT included in the price.
