WanHao Duplicator 6 Ultimaker2 V1.5 Mainboard for 3D Printer

Description The Ultimaker 2 motherboard is based on the ATmega 2560 16U2 main chip platform The board integrates 5 A4988 stepping drive circuits The interface board integrates an SD card slot coding navigation keys LCD display All technical details are exactly the same as Ultimaker2 Default Ultimaker2Marlin official firmware support single or double nozzle printingFeatures 1 Based on MEGA 2560 single board solution higher stability2 Two heating ends supporting two color printing the maximum operating temperature depends on the material of the thermal head 3 Support hot bed the maximum current does not exceed 9A and the temperature is recommended to be controlled below 100°C 4 Power supply 19 24V DC use laptop power supply or switching power supply 5 Three channel temperature sensor PT100 200 650℃ using Texas Instruments INA826 special chip higher precision and strong anti interference ability6 Three way limit switch default reset position 0 default structure size 230 225 2057 High scalability one ANALOG IN is reserved and other idle I O ports are also reserved for pin headers which can be expanded by users8 Two way Safety switch can be connected to smoke sensors etc to prevent safety accidents 9 Three way fan interface adjustable fan interface J14 FAN PWM 24V 5V fan J34 FAN 5V 24V fan J20 FAN 19 24V 10 Dimmable LED interface J15 LED PWM 24V 11 ULTIMAKER2 motherboard Applicable model Wanhao Duplicator 6Package Included
