WNB 10ML Green Oil UV Solder Mask Ink BGA PCB Paint Prevent Corrosive Arcing Soldering Paste Flux Inks Soft Nylon Brush

WNB 10ML Green Oil UV Solder Mask Ink BGA PCB Paint Prevent Corrosive Arcing Soldering Paste Flux Inks Soft Nylon Brush
Eachine1
sku: 1622074
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$10.99
Shipping from: China
   Description
Features 1 Green oil a liquid photo solder resist is an acrylic oligomer 2 Due to the special nature of the material the solder mask oil will not dry naturally UV curing is required 3 As a protective layer it is applied to the circuit and substrate on which the printed circuit board does not need to be soldered or used as a solder resist 4 The purpose is to protect the formed line pattern for a long time Specification Model WNB W 001 solder mask green oilMaterial Acrylic oligomerDielectric strength 500V milSolvent resistance Trichloroethane boiled for 2 minutes without falling offSolder resistance 255 265 degree 10s 3 timesHardness 5HCuring condition UV lightCapacity 10ccApplication PCB board repair essential materialsGross weight About 55 0g set Applications 1 Prevent physical disconnection of the conductor circuit 2 In the welding process the short circuit caused by the bridge is prevented 3 Welding only in the parts that must be welded to avoid solder waste 4 reduce copper contamination of the welding trough 5 Prevent deterioration and corrosion of insulation due to external environmental factors such as dust and moisture 6 It has high insulation and makes it possible to increase the density of the circuit Instructions 1 Apply the soldering mask oil ink to the motherboard that needs to be repaired Please apply as evenly as possible and make sure the coating is not too thick 2 Use the UV flashlight to curing the coating Since the pow
