Vibration Transmitter LHZD-BSQ-II 24vdc 20mA Murah

The LHZD-BSQ-II type two-wire integrated vibration transmitter integrates the vibration velocity sensor and the precision measurement circuit, and realizes a two-wire loop.
The function of the vibration measurement system in the "sensor + transmitter" mode realizes an economical high-precision vibration measurement system. The transmitter can be directly connected to DCS,
PLC or other systems are easier to maintain and more economical than three-wire transmitters, and are ideal for vibration measurement of factory equipment such as fans and pumps.
Installation position: Install vertically or horizontally on the vibration point to be measured, and fix the bottom of the transmitter with M10 screws.
parameter:
1. Sensitivity: 20mv/mm/s±5%, 30mv/mm/s±5%, 50mv/mm/s±5%
2. Frequency response: 5 to 500 Hz
3. Measuring range: 0～500μm or 0～50.0mm/S
4. Output current: 4～20mA (two-wire system)
5. Output impedance: ≤500Ω
6. Working voltage: DC24V
7. Large acceleration: 10g
8. Measurement direction: vertical or horizontal
9. Use environment: temperature -30 ℃ ~ 50 ℃ relative humidity ≤ 90%
10. Installation thread: M10×1.5
Ordering Guide:
Model selection code: LHZD-BSQ-II—A□□
Range selection A□□:
01— 0～10mm/s; 02*— 0～20mm/s; 03— 0～50mm/s; (vibration intensity)
04— 0～100um; 05— 0～200um; 06— 0～500um; (vibration displacement
