VeliToy Mounted 1.8-50Mhz ATU-100mini Automatic Antenna Tuner Accessories with 0.96Inch OLED

Features: Assembled no need for soldering ready to use! NO Need to burn firmware Circuit schematic and firmware please contact us. With 0.96 OLED Notice: Actual color may be slightly different from the image due to different monitor and light effect Please allow 1-3cm deviation due to manual measurement Description: All information about project can be found on GitHub (N7DDC). Power supply range: 10 - 15 VDC Max current: 450mA Max working power: 100 watts Max measured power: 150 watts Minimum power for tuning start: 1 watt Recommended maximum power while tuning is not above 30 watts. (after tuning you can use 100 watts and work on this power) Minimum measured power: 0.1 watt Step for measurement on powers below 10 watts: 0.1 watts Step for measurement on powers above 10 watts: 1 watt Power measurement accuracy: 10% Maximum installed capacity: 1870 pF Minimum step for setting capacity: 10 pF 100 watt tuner 7x7 (7 capacitors x 7 coils) based on PIC 16F1938. Dimentsion - 120mm x 62mm.
