Vaina Trenzada de Poliéster Elástico 25 mm Gris

Código ErreBi: 16945 Diametro: 25mm Temperatura de trabajo: -50° / +150° Venta por metros Braided mono-filament polyester, resistant to abrasion, chemicals, mildew, UV rays and marine atmosphere. Suitable for protection of electrical cables, adhering perfectly to the article, since its power to expand up to twice the nominal diameter. He cuts through the appropriate size sheath heat to prevent fraying. Color: black and gray. Insensitive to water. No toxicity. Polyester yarn diameter: 525 mm 0.22 dtex Operating temperature: - 50 ° C / + 150 ° C Max continuous use: 120 ° C Max in alternate use: 180 ° C Self-extinguishing flammability rating: UL 94 HB Oxygen index LOI 27.5 Melting point: 260 ° C Softening point: 230 ° C / 240 ° C Water absorption in normal climate: 0.4% Water absorption at saturation: 0.5 - 0.6% Maximum elongation at break: 23-28% Withdrawal H2O at 100 ° C x 3: 2 - 10% Scheda Tecnica Material: Poliéster Color: Gris Temperatura de funcionamiento: -50°C a +150°C Diámetro
