VTX5848 LITE 48CH 5.8G 25/100/200/400/600mW Switchable FPV RC Drone VTX Video Transmitter Module OSD Control

VTX5848 LITE 48CH 5.8G 25/100/200/400/600mW Switchable FPV RC Drone VTX Video Transmitter Module OSD Control Frequency adjustment: 1. manual adjustment------RF button, switching frequency Short press, switching channel, 4 white LED lights indicate channel Long press(2s) switching group, 3 blue LED lights indicate group 48CH channel list: 2. the wiring diagram of OSD adjustment Power switching: POW button------power adjustment Press once, switching one power (25mW, 100mW, 200mW, 400mW, 600mW) 600mW in default. Specification: Item name: VTX5848 LITE FPV video transmitter Input voltage: DC 7-27V Input current: 16.4V(4s) 600mW=360 MA10MA Output voltage: DC 5V 1A Output power: 25/100/200/400/600mW switchable Channel: 48CH Frequency switch: manual button/OSD (simultaneous support) Connector: MMCX (with sma extension cable) Size: 36x36x9mm Mounting hole: 30.5x30.5mm, M3 Weight: 6.4g (without antenna and connector) Features: -Stable output power, long transmission distance -Fast 5-speed power switch, independent two red indicator, indicating the current output power 25/ 200/ 400/ 600MW -Using 4*3 LED display 48 channel -Support OSD signal remote frequency control, support PIT mode ( omW output power only can be open in OSD) -With power filter -Antenna using MMCX to SMA (with 100MM extension cable) reducing the space -Strong power chip, input up to 27V, output 5V/1A low ripple, less interference -Do not install antenna to power up, and it will not burn the VTX -30.5mm*30.5mm mounting hole distance, suitable for CC3D, NAZE32, F3, F4, F7 flight controller Package included: 1x VTX5848 LITE FPV video transmitter 1x 6P*1.0mm Connector cable 1x MMCX-SMA coaxial cable
