VStarcam C37-AR Dual Antenna 720P Smart Alarm IP Wireless Camera ONVIF RTSP Protocol IR Night Vision

Description : VStarcam C37-AR Dual Antenna 720P Smart Alarm IP Wireless Camera ONVIF RTSP Protocol IR Cut Night Vision Features : ASK linkage alarm function. Dual antenna. Specification : System OS Embedded Linux OS system security Three level user authority management online users support 4 online visitors simultaneously DDNS Free DDNS Control protocol ONVIF 2.4 protocol, high interoperability Processor Hisilicon processor,built-in ARM926 @Max. 440MHz and a high-speed video co-processor. Reset Long press for 15 seconds to restore back to factory settings Collection Image sensor 1/4inch 720p Progressive scan CMOS sensor CMOS support AWB, AGC, BLC sensor size 3.84mmx2.16mm SNR 39dB Minimum illumination 0.8Lux/F1.4 (colourful model ),0.3Lux/F1. (B&W mode) Lens/viewing angle [email protected]/56.14 Night vision Dual IR-CUT filter auto switch, 9pcs 850nm5mm LED,10m IR distance IR control IR turned on: night vision view enabled, infrared Ray, ICR auto detect. IR turned off: night vision disabled, infrared ray off, ICR stay in day view mode. Video Compression Format H.264 Main Profile/H.264 Baseline Profile/MJPEG/JPEG Baseline Video coding process Multi-stream: 720P/24fps+VGA/30fps+QVGA/30fps+720P @1fsJPEG snapshot Resolution 720p/VGA/QVGA Bit Rate CBR/VBR, output bit rate range: 128-4096kbps Frame rate 25fps Picture Adjustment Contrast, brightness, saturation, chroma are adjustable. Audio Input Built in -48dB Microphone Output Built in speaker(81W) Sampling frequency / width 8KHz/16bit Compression format ADPCM/32kbps Network Interface 10Base-T / 100Base-TX, RJ45 connector Network Protocol TCP/IP,HTTP,TCP,UDP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPnP,RTSP,P2P,ONVIF etc. WIFI WiFi802.11b/g/n Antenna 3dBi antenna, stronger signal, more stable Wireless network security one key setup WiFi, do not need network cable . storage Storage mode Local storage / client storage card support 64G TF card . Interface Micro SD Pan-Tilt P/T Pan: 355,Tilt: 120 Preset Postion support up to 15 preset postions Limit method Software limit position, more accurate preset positions,lower Pan Tilt failure rate Alarm Alarm action Sensors: ASK encoding, millions of encoding library, can support most sensor's factories which in provided in VStarcam software list, like door sensor, pir sensor, smoke detector, gas detector and etc. Eye4 APP ASK module's compatibility RF: 433MHz, transmit distance>80meters. Sensor definition: sensor's category and type Physical index Rated Voltage DC5/2A0.3V Power comsumption Rated power: 3.0W(IR ON) Working environment Working Temperature: -20-70 Working Humidity: 90% Weight Gross Weight : 755g (Note: in kind prevail) Housing material ABS plastics Camera size 195x140x130mm (LxWxH) Installation Wall mounting, ceiling mounting Package includeds : 1 x VStarcam C37-AR Dual Antenna Camera 1 x Power Adapter (EU / US / AU / UK Plug for Optional~) 1 x Camera Holder 1 x English User Manual 4 x Screw Details pictures :
