VONETS VBG1200 300Mbps+900Mbps Dual Band Wireless Router Repeater WIFI Base Station with 4 Antennas

1. Support wide voltage DC5-15V power supply, two-level automatic overvoltage protection (protection voltage upper limit 15.5V)2. The output power of the power supply is not less than 10W (typical power supply 5V/2A, ripple less than 100mV)3. Module power consumption: 1.3W - 3.75W4. WiFi working frequency band: 2.4G + 5G5. Wireless transmission rate: 300Mbps(2.4G)+900Mbps(5G)6. Transmit power: 2.4G is 15dBm/16.5dBm optional, 5G is 19dBm/23dBm optional7. Point-to-point barrier-free transmission distance: 500 meters (5G frequency band)8. The module has a built-in low-noise amplifier (LNA) with a receiving sensitivity of 14dB9. Standard external antennas: 2 3dBi 2.4G antennas, 2 3dBi 5G antennas10. Using digital-analog temperature compensation and frequency stabilization technology, the WiFi signal is more stable and not easy to drop11. The aluminum alloy shell has good heat dissipation characteristics, which can quickly dissipate the heat generated when the equipment is working12. Working environment temperature: -20 to 50 degrees Celsius13. Support WiFi intelligent bridge relay, which can realize the functions of wireless to wired and wired to wireless14. Support 802.11ac, 802.11a, 802.11n and other WiFi transmission protocols15. Support WiFi hotspot automatic reconnection, two hotspot matching methods: full matching authentication mode, SSID and password authentication mode16. Support WiFi hotspot memory, memorize 100 hotspots17. Support simultaneous connection of more than 20 WiFi terminal devices18. Support SSA protocol, built-in hotspot signal strength detection and reporting function, realize WiFi mobile positioning19. Supports forced shutdown of hotspots and forced shutdown of WiFi hardware20. WiFi hotspot connection parameter import and export function21. Adopting VDNS virtual domain name configuration technology to ease user configuration difficulties22. Using WEB management, you can freely switch between Chinese and English configuration interface23. Support online upgrade24. Support two bridge modes of IP layer transparent transmission and MAC layer transparent transmission to meet various bridge applications25. Dimensions: 84x45x15mm26. Weight: 133.8g
