VEVOR Boîte à outils pour mini tour à métaux et mini fraiseuse 500 w 250 mm

***This listing includes 1 Tool Kit of this milling machine ONLY!!!***
Detailed Introduction of This Drilling/Milling Machine are As Follows:
This
mini drilling/milling machine with lathe bed can handle most materials.
It has a 550watt motor with variable speed drive, The working table
with t-slots can enable clamping of workpieces and metric graduated
compound scales. The machine also incorporates a tilting column which
allows drilling/milling of workpiece at ±90° from vertical. It is
supplied with 13mm chuck accessory kit. for adjusting and setting.
The lathe bed is made of high grade iron. The rigidity of lathe, the handiness
and accuracy of the v-slideways are obtained by raw materials, heat
hardening and grinding. This machine is DC motor driven. The spindle
speed is variable from 20-2500rpm. The feed speed can be adjusted
according to the requirements of different workpieces.
Application
1. This is a quality mini mill Ideal for the professional engineer or model maker alike.
2. The precision mini lathe is designed to preform various types of processing jobs. Counterface timing,
drilling, threading, and cutting jobs on materials made up of round bar
and bar materials can be preformed with this machine. The machine can
be used in areas such as mini precision parts processing, sample
processing and modeling works.
Note
This machine is suitable to use only from 12°C-35°C（53.6℉-95℉).
Head swivels ±90° vertically
Adjustable gibs on table precision
Adjustable stops on table
Straightforward gear drive mechanism
Robust construction
Extra wide cross table
Chuck Arbor Bolt provides tightening of drilling chuck through the spindle
Rack and pinion feed for drilling operations
Safety guard with microswitch according to EU-requirements
Available in metric leadscrews
START / STOP switch incorporates emergency STOP
Motor power: 550W
Drilling capacity: 13mm /0.51"
Face milling capacity: 30mm /1.18"
End milling capacity: 16mm/0.63"
Longitudinal travel: 100mm/3.94"
Cross travel: 250mm /9.84"
Spindle stroke: 200mm /7.87"
Working table size: 460X 112mm/18.11"x4.41"
Max distance spindle to table: 220mm /8.66"
Spindle taper: MT3
T-slot: 10mm /0.39"
Spindle speed: 20 - 2500rpm
Spindle rotary angle: -45°~+45°
Dimension: 368X673X685mm /14.5"x 26.5"x27"
X-Axis Travel Bed: 300mm/11.81"
Y-Axis Travel Bed: 140mm/5.51"
Z-Axis Travel Bed: 220mm/8.66"
Table Size: 460*110mm/18.11"x4.33"
Tool Kit Gross Weight: 17 kg/37.5 lb
Tool Kit Packege Dimensions (L x W x H): 68 x 21 x 18 cm/26.8" x 8.3" x 7.1"
1 X Tool Kit
