VC4091A/C High Precision Digital Bridge Capacitance Resistance Inductance Measure LCR Meter Electronic Component Tester

Features ● Measurement frequency up to 100kHz● Test level 100 2000mV●Support the measurement of DCresistance and electrolytic capacitor●Internal bias voltage output 1mV 1500mV ●Automatic identification ofcomponent measurement●3 5 inch TFT display 5 and a half bits display●USB RS232 communication interface Handle sorting● Data recording function maximum andminimum values average value ● Support SCPI communication protocol● Provide system settings which can configurelanguage buzzer screen brightness etc accordingto the needs of users ● Basic accuracy 0 2 ● Manual and automatic range● Be equipped with open circuit andshort circuit correction● Comparator has sorting and alarm function● Provide a variety of test portsSpecification ModelVC4091AVC4091CDigitsMain parameter 5 digits secondary parameter 5 digitsMeasurement ParameterMain parameter L C R Z secondary parameter X D Q θ ESRMeasurement Range L 0 001μH 9999HMeasurement Range C 0 001pF 9999μFMeasurement Range R 0 0001Ω 99 99MΩBasic Accuracy0 10 Test Frequency Hz 10 10kHz10 100kHzContinuously adjustable 1Hz Continuously adjustable 1Hz Measurement2 times second slow 5 times second medium speed 10 times second fast Internal Bias0 1500mV adjustable 1mV steppingTest Level0 1V 2VContinuously adjustable 1mV Correction FunctionOpen circuit correction short circuit correctionScreening functionThe screening limit can be set from 100 to 100 with fixed points of 10 25 50 Selection of comparatorFive
