VALQUA GASKET CUTTER ORIGINAL JAPAN gasket alat potong

VALQUA CUTTER MADE IN JAPAN
BY NIPPON VALQUA INDUSTRIES
Product name : Gasket Cutter
Features
- This is a set of convenient tools to easily
cut out flange gaskets at a construction site
or for assembly work.
- The supporting iron has scale marks,
which allows easy and accurate size
adjustments.
sold separately, it is possible to cut out
- It is highly recommended to keep this tool
as an indispensable workshop tool not only
in the maintenance department of a
chemical plant, oil refinery or iron plant, but
also in the assembly area of machine or
equipment manufacturers as well as in pipe
laying companies.
Cutting range :
- Minimum diameter 50mm
Maximum diameter 540mm
sold separately, it is possible to cut out
Placing part orders:
- Parts worn after long years of operation
should be replaced with new parts. Orders
for single items are also accepted when
certain items are missing.
(For cutter blades , one replacement set
consisting of five blades is available)
- Instructions for use:
1. First, insert the straight core needle or the
bending type core needle at the bottom of
the floating pole of the needle core , and fix
it using the pressure bolt for the needle
core In this case, use the bending type
core needle if the cut diameter is up to 50
mm, and use the straight core needle for a
cut diameter larger than 50 mm.
2. Next, at the groove of the floating pole of
the cutter blade , attach the blade with two
pressure bolts from the cutter blade .
3. Thread the supporting iron into the
floating pole of the needle core and the
floating pole for the cutter blade
4. Set the part marked with "" of the floating
pole of the needle core to zero to match the
supporting iron as shown in Figure A, and
firmly tighten with the knob.
5.
