Universal 7 Keys V29 V56 V59 TV Switch Keypad Board With Interface

Universal 7 Keys V29 V56 V59 TV Switch Keypad Board With Interface
Eachine1
sku: 955688
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$3.61
Shipping from: China
   Description
Universal 7 Keys V29 V56 V59 TV Switch Keypad Board With Interface Description: 7 Keys Keypad Board, can be directly used in V29 V56 V59 TV driver board with interface, can be welding infrared receiving head PIN Symbol Description 1 + 5 V + 5 V POWER SUPPLY FOR IR 2 IR - IN IR INPUT 3 GND GROUND 4 K0 POWER 5 LEDR RED LED 6 LEDG GREEN LED 7 GND GROUND 8 K1 MANU 9 K2 INPUT SOUR 10 K3 VOL+ 11 K4 VOL- 12 K5 CH+ 13 K6 CH- 14 K7 RESERVED Package included: 1 x 7 Keys Keypad Board
