Ultra3000 4.9G-5.8G 56CH 3W VTX 7~36V Input FPV Transmitter for FPV RC Drones

Specification Model Ultra3000 VTX 4 9G 5 8G 3W Input Voltage DC 7 36V 2 8S Battery Output 5V 600mA Power 5V to camera Input Impedance 75Ω Protocol IRC Tramp Shell Material Aluminum Alloy Heat Dissipation mode Active Cooling Fan Specifications 20mm20mm6 5 12000rpm Antenna Connector MMCX Connector Cable Connector GH1 25 6P Connector Output Power 25mW 400mW 800mW 1500mW 3000mW Pit Mode Frequency tables 56 CH Video Format PAL NTSC Microphone Built in Microphone Size 37mmx29mmx15mm Weight 23g without cable Mounting Holes 20mmX20mm M2 Features 3W super power suitable for Long Range flight with good stability Six power levels 25mW 400mW 800mW 1500mW 3000mW Pit mode Two layer board cooling structure separate power BEC and main board reducing and shielding from the insinal interference Temperature control protection function that can prevent high temperature burning Selected high strength aluminum alloy CNC housing auxiliary cooling Built in micro turbine fan active cooling rotating speed of 12000 rpm Wide voltage input supports 7V 36V voltage input VTX control protocol is IRC Tramp supports OSD parameter adjustment VTX built in microphone real time return of Drone s sounds Has 3 regional frequency tables to meet the needs of various regions One function buttons three indicator lights easy to operate Mounting holes is 20mmx20mm Support IRC Tramp Protocol Ultra3000 VTX supports the IRC TRAMP protocol and the modification of video transmi
