USB Motion Controller Manual CNC Motion Controller Milling Lathe For CNC Router Engraving Machine

USB Motion Controller Manual CNC Motion Controller Milling Lathe for CNC Router Engraving Machine Specification: The motion controller adopts high performance 32 bit CPU and high performance FPGA equipped with 7 inch LCD display. Humanized window man-machine interface. Memory uses external USB with built-in 8GTF card large storage space. With touch type keyboard the system has the characteristics of high reliability high low noise and easy operation. The controller has 5 linkage and multi-micro segment forward-looking control algorithm which can realize five linear interpolation and five multi-micro multi-line continuous interpolation and has break line continued carving control power-off storage coordinate function. Support the hand wheel control interface. Simple and clear parameters are convenient and quick for your operation. The input/output setting functions are convenient for your use and maintenance. Features: 1. Parameter Setting: Various control parameters related to processing and operation can be set to achieve better processing effect. 2. Manual Operation: It can realize manual jog back to program back to mechanical coordinate clearing and other operations. 3. Program Management: Program can create delete modify read save copy and paste automatic processing continuous pause. etc. 4. Externally Manual: A variety of externally manual functions can be defined for easy use. 5. External Handwheel Controller: You can set the step size of each step supporting both position and speed modes. 6. Tutorial Function: Can define external input and panel control input. 7. Choose Input Function Freely: Enable input ports to achieve various users needs System Composition: The CNC system is mainly composed of the following parts: 1. High performance high speed 32 bit ARM CPU high-performance FPGA 2. 7 inches LCD screen resolution: 800 x 480 3. Input/output 16-channel opto-isolated 10mA inputs 8-channel opto-isolated pull-down 500mA output Specification: Standard data unit 0.001mm General accuracy: ±2PP Continuous straight-line corner accuracy: 1/4 of the corner bow height under normal state . data size: ±99999.999mm . pulse output frequency: 500KHz all of five can be 500KHZ at the same time Number of control : 5 X Y Z A B Number of linkage : 5- linkage and 5- multi-micro multi-line forward-looking interpolation control Support U disk built-in memory which can expand to 32G Weight: Approx. 1174g/41.4oz Package list: 1 x 5 Offline Motion Controller Note:Please note that the new type and old type of this product will be sent randomly and make sure you will not mind before ordering.
