USA Lab 50L Single Jacketed Glass Reactor Turnkey System (Optional ETL Certification to UL and CSA Standards for Reactor) - USAlab

The USA Lab Single Jacketed 50l Glass Reactor system is the best reactor kit on the market. This kit comes with a USA Lab Heater chiller that can bring your reactor down to a freezing temperature of -40°C and all the way back up to the high temperature of 200°C. This allows users to have accurate temperature control and a large range of temperature for a variety of applications. With each kit comes the MD 4C NT 2.2CFM Chemistry Diaphragm Pump a top tier vacuum pump from Vacuubrand. No expense has been spared with this reactor turnkey system yet we crush the market on pricing to provide great value at a low cost. Our reactor turnkey systems are the best value on the market and each one comes with fantastic customer service local product support and a 1-year warranty. Bring your lab to the next level and get started with a USA Lab single jacketed reactor turnkey system today! *NOTE: When paired with a reactor fluid requirement is nearly 9 gallons* ETL only applies to reactor -THIS SYSTEM INCLUDES- •1x: USA Lab 50L Single Jacketed Reactor JR-50 •1x: USA Lab 12L -40°C to 200°C Heater Chiller UHC-50/40 •1x: USA Lab 50L -30°C Chiller UC-50/30 •1x: Vacuubrand MD 4C NT 2.2CFM Chemistry Diaphragm Pump •4x: 5 Gallon Buckets of Propylene Glycol -REACTOR INFORMATION- JR REACTOR FEATURES • ETL to UL and CSA Standards (Optional) Reactor only >INTERTEK CSA CERTIFICATIONINTERTEK UL CERTIFICATION< • All glassware is made from high grade borosilicate glass that is durable and resistant. • Wide range of temperature operations -80°C to 210°C • All seals are PTFE to increase durability and longevity. PTFE is resistant to a large portion of solvents and chemicals. • Rugged High RPM stirring motor for superior stirring power. • Large condensing area for faster condensing. • Durable stainless steel support frame with casters. • 1 Year warranty with US base parts and support. JR REACTOR SPECIFICATIONS Model JR5 JR10 JR20 JR50 (INCLUDED) JR100 Vessel Capacity 5L / 1.32Gal 10L / 2.6Gal 20L / 5.28Gal 50L / 13.20Gal 100L / 26.41Gal Material Flask Capacity 1L / 0.26Gal 2L / 0.52Gal 5L / 1.32Gal 5L / 1.32Gal 5L / 1.32Gal Receiving Flask Capacity Not included 5L / 1.32Gal 5L / 1.32Gal 10L / 2.6Gal 10L / 2.6Gal Fluid Jacket Capacity 0.8L / 0.21Gal 8L / 2.11Gal 9L / 2.37Gal 16L / 4.22Gal 25L / 6.60Gal Glass Material GG-17 Borosilicate Glass | Thickness: 6.5mm ±0.5mm Rotary Speed 0-450RPM Glass Temperature Range -80°C to 250°C / -112°F to 482 Power Requirements Non-ETL: 110-120V 60Hz 15A 1p | ETL: 230V 60Hz 15A 1p Stirrer Wattage 90W (ETL 120W) 90W (ETL 120W) 90W (ETL 120W) 90W (ETL 120W) 250W (ETL 200W) Lowest Vacuum Level 0.098Mpa / 25 Torr / 25000 Microns Speed Regulation Digital Step-Less Condenser and Feed Valve Barbs 10MM - 3/8 Bottom Drain Port 35MM - 1 3/8 Receiving Flask Barb 16MM - 5/8 Jacket Pressure Maximum 29 psi - Nominal 25 psi Fluid Connection 16MM - 5/8 barb or 1/2 NPT (100L: 5/8 Barb or 3/4 MNPT) Certification ETL to UL and CSA Standards (Optional) External Dimensions LxWxH 16 x 18 x 68 20.4 x 20.4 x 70 39 x 20.4 x 79 41 x 23 x 90 48 x 34 x 102 Weight 75 lbs 149 lbs 176 lbs 205 lbs 275 lbs JR REACTOR PACKING LIST Model Quantity Vessel with Rack (Pre-assembled) 1 Main Condenser 1 Material Flask 1 Receiving Flask 1 Reflux Flask 1 C Clamp Valve 1 Feed Ports 6 Sets Stopper 1 Clamp for Material Flask 1 Strap for Condenser 1 Set Sealing Screw / Flange 3 Sets Fluid Line Sealing Clamp / Flange 2 sets Control Box 1 Vacuum Gauge 1 Support Rings 2 Stirring Motor w/ Paddle 1 Temperature
