UNI-T UTR2811D LCR Digital Bridge 10kHz Resistance Capacitance Inductance Meter Electronics Measuring High Precision Tes

Features Economical and practical LCR digital bridgeComprehensive measurement parameters stable readingsLarge character LCD display clear and intuitiveUsing SMT surface mount technologyThe fastest measurement speed is 20 times sec which meets the requirements of the test systemTwo output impedance options 30Ω 100ΩSpecification Measurement parameters Main L C R Z Sub D Q θ X ESRBasic accuracy 0 20 Equivalent circuit series parallelDeviation mode 1 5 10 20 Range mode automatic keepTrigger mode INT MANTest speed fast 18 medium speed 6 slow speed 3 times second Correction function open short circuit clearTest segment configuration 5 endDisplay mode direct readingDisplay large screen white backlit LCD Test signal Test frequency 100HZ 120HZ 1KHZ 10KHZOutput impedance 30Ω 100Ω Test level 0 1Vrms 0 3Vrms 1Vrms Measuring display range Z R X ESR 0 00001Ω 99 999MΩC 0 01pF 99999μFL 0 01μF 99999HD 0 0001 9 9999θ Deg 179 9° 179 9°θ Rad 3 14159 3 14159Q 0 0001 999 9△ 999 99 999 99 Comparator and interface Comparator fixed percentage 5 files sorting and ringingInterface none power supply Power supply voltage 99V 121V 198V 242VFrequency 50Hz 60HzFuse 0 5A T 250V Surroundings 1 Temperature range Operation 0°C 40°CNon operation 20 ° C 70 ° CCooling method natural cooling 2 Humidity range Operation ≤90 relative humidity below 35 °C Non operation 35 ° C 40 ° C ≤ 60 relative humidity 3 Altitude Operatio
