UNI-T UPO2104CS 8" TFT LCD 100MHz 4 Channels 1GS/s Ultra Storage Oscilloscope

Description UNI T UPO2104CS 8 TFT LCD 100MHz 4 Channels 1GS s Ultra Storage OscilloscopeBrand UNI TFeatures 1 Sample Rate up to 1GS s 2 Channels 2 4 3 Bandwidth 100MHz 160MHz 200MHz 4 Memory Depth 32Mpts Standard 5 Waveform Capture Rate up to 30 000wfms s 6 With 256 level intensity grading display 7 Up to 65 000 frames for Waveform Record Replay 8 Support serial bus trigger and decoding 9 8 inches TFT LCD WVGA 800 x 480 10 Interface USB Host USB Device LAN VGA AUX OUT 10MHz input output Specification ModelsUPO2104CSBandwidth100 MHzChannels4Sample Rate1GS sMax Memory Depth32MptsWaveform Capture Rate30 000wfms sTime Base Scale2 ns div 至50 s divInput Coupling 1M 1 13 pF 3 pF Vertical Scale1mV div 至20 V div 1 M DC Gain Accuracy3 Waveform Record65 000 FramesTriggerEdge Alternate Runt Super picture Nth Edge Delay Duration SetupHold Pulse Width Slope Video Pattern RS232 UART I2C SPI USBBus DecodeStandard Parallel Optional RS232 UART I2C SPI USBWaveform OperationA B A B AB A B FFT Editable AdvancedAuto MeasurementPeak Peak Value Amplitude Maximum Minimum Top Value Bottom Value Mean Average Root Mean Square Value Overshoot Preshoot Frequency Cycle Rise Time Fall Time Positive Pulse Negative Pulse Positive Duty Ratio Negative Duty Ratio Delay 1 2 and Delay 2 1 Number of MeasurementsDisplay 5 measurements at the same timeMeasurement StatisticAverage Max Min Standard Deviation Number of MeasurementsFrequency Counte
