UNI-T UPO2104CS 8" TFT LCD 100MHz 4 Channels 1GS/s Ultra Storage Oscilloscope

Description: UNI-T UPO2104CS 8" TFT LCD 100MHz 4 Channels 1GS/s Ultra Storage Oscilloscope Brand: UNI-T Features: 1.Sample Rate up to 1GS/s. 2.Channels 2/4. 3.Bandwidth 100MHz, 160MHz, 200MHz. 4.Memory Depth 32Mpts(Standard). 5.Waveform Capture Rate up to 30,000wfms/s. 6.With 256 level intensity grading display. 7.Up to 65,000 frames for Waveform Record ,Replay. 8.Support serial bus trigger and decoding. 9.8 inches, TFT LCD, WVGA(800 x 480). 10.Interface: USB Host, USB Device, LAN, VGA, AUX OUT, 10MHz input/output. Specification: Models UPO2104CS Bandwidth 100 MHz Channels 4 Sample Rate 1GS/s Max. Memory Depth 32Mpts Waveform Capture Rate 30,000wfms/s Time Base Scale 2 ns/div 50 s/div Input Coupling ( 1M 1%) ||( 13 pF 3 pF) Vertical Scale 1mV/div 20 V/div( 1 M) DC Gain Accuracy 3% Waveform Record 65,000 Frames Trigger Edge, Alternate, Runt, Super picture, Nth Edge, Delay, Duration, SetupHold, Pulse Width, Slope, Video, Pattern, RS232/UART,I2C,SPI, USB Bus Decode Standard: Parallel; Optional: RS232/UART,I2C,SPI, USB Waveform Operation A+B, A-B, AB, A/B, FFT, Editable Advanced Auto Measurement Peak-Peak Value, Amplitude, Maximum, Minimum, Top Value, Bottom Value, Mean, Average, Root Mean Square Value, Overshoot, Preshoot, Frequency, Cycle, Rise Time, Fall Time, Positive Pulse, Negative Pulse, Positive Duty Ratio, Negative Duty Ratio, Delay 1->2, and Delay 2->1. Number of Measurements Display 5 measurements at the same time Measurement Statistic Average, Max, Min, Standard Deviation, Number of Measurements Frequency Counter Hardware 6 bits counter (Channels are selectable) Standard Interface USB-Host, USB-Device, LAN,10MHz Input/Output, AUX Output (TrigOut, Pass/Fail) General Characteristic Power 100V~240VACrms, 45Hz~440Hz Display 8 inches, TFT LCD, WVGA(800480) Product Color White and Gray Product Net Weight 3.5 Kg 0.2 Kg Product Size (WHD) 336mm 163.8mm 105mm Standard Accessories Probe2/4(1,10 switchable),Power Cord ,USB Cable, PC Software CD Standard Individual Packing Gift Box, English Manual Package included: 1 x UNI-T UPO2104CS Ultra Storage Oscilloscope 2/4 x Probe(1,10 switchable) 1 x Power Cord 1 x USB Cable 1 x PC Software CD 1 x Gift Box 1 x English Manual Details pictures:
