Trianglelab® / Dforce® M8 mini inductive proximity sensor DC5V 3-wire 2mm Z probe auto bed leveling CR10 ENDER3 prusa mi

▉NAME M8 MINI inductive proximity sensor Triangleab customization ▉Introduction A small size inductive sensor for you to adding an accuracy reliable Z probe on your printer Enable Auto bed Leveling for your low cost 3D printer The performance of M8 MINI and M8 proximity switch sensors are the same but M8 MINI has a lightweight design The length is shorter and the weight is lighter Easier to install and reduce the total weight of the entire extrusion head KIT ▉Datasheet Diameter of Head 8mmDetecting Distance 2mm±10 Output TypeNPN normal contactedSupply VoltageDC5VCurrent Output 300mAResponse Frequency 150HzDetect Object IronOperating Temperature 25°C to 55°C Non freezing Condition ▉Wiring Brown→ 5VBlue→ GNDBlack→ Signal Zmin How to install this sensor to ender3 CR 10 printer or some other Melzi boards printer1 Flash a Bootloader https letsprint3d net 2018 07 22 guide how to flash a bootloader on melzi boards 2 Upload Marlin 1 1 9 Firmwarehttps letsprint3d net 2018 07 31 guide how to setup auto bed leveling ender 3 https github com LetsPrint3D ender 3 marlin abl firmware 1 1 93 Fixing the sensor to your print head Make sure the sensor tip is 1MM higher then your nozzle 4 Wiring and cable management 5 Testing and tuning6 Happy printing
