Touch Panel 300Mbps Wireless Access Point - White

Touch 360 is a stylish in-wall WiFi Access Point, which is specially designed for existing building structure, without affecting the appearance of the interior design. The design can provide users with convenient wireless local area network (WLAN). The Touch 360 is designed with standard 86 x 86 mm European Outlet Box size and can be installed in the existing building structure to easily construct a wireless network. Thus, it helps system integrator save time, cost and human resource.
It is a best-in-class 802.11n indoor access point designed specifically for business-class
environments such as hotels, airports, coffee shops, shopping centers, sporting venues, and university campus Integrated Power over Ethernet (PoE) allows installation in areas where power outlets are not readily available.
Features
Perfect flat plate, smooth and gorgeous European 86 type wall outlet compatibility Design.
Capacitive touch sense, Very sensitive touch control just like phone touch.
Front panel is high quality crystal glass, scratch and humid resistant, will never fade.
Various color and design panels are available.
With LED indicator, can find the position of the switch easily in darkness, very distinguished.
600Mhz MTK7620N RF Chipset, 802.11b/g/n Support.
32MB SDRAM + 4MB Flash Build-in for Higher Performance.
Gateway / Wireless Client / AP operation modes.
Passive 24V PoE supports up to 70 meter (200 feet) deployment.
Central AP Control Management Software Support.
Specifications
Wireless
Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Data Rate 300Mbps
Frequency Band 2.4~2.4835GHz
Wireless Transmit Power 11n MCS7:19±1dBm, 11g 54Mbps:19±1dBm, 11b 11Mbps:20±1dBm
Receive Sensitivity 11N MCS0@-83dBm ; MCS7@-65dBm, 11G 54Mbps@-82dBm ; 6Mbps@-95dBm, 11B 11Mbps@-85dBm ; 1Mbps@-95dBm
Operation Mode Gateway, Repeater(Extender), AP(access point)
Wireless Security 64/128-bit WEP, WPA/WPA2, WPA /WPA2-Personal (TKIP/AES)
System Requirements Windows 7/Vista/XP/2000,Mac OS®, Linux or Android OS, IOS
Hardware
Interfaces 1 x RJ-45 for 10/100 Mbps(One for POE)
MCU MTK7620N
SDRAM&FLASH 32MB+4MB
Button 1 x Reset button(Reset & Factory Defaults)
LED Indicator Power
Antenna 2x built-in 2dBi omni-directional Antenna
Power Supply POE 24V
Software
Wireless Function Distance Control (802.1x Ack timeout), Multiple SSID (4 SSID), BSSID
Security WEP Encryption-64/128/152 bit, WPA/WPA2 Personal (WPA-PSK using TKIP or AES), WPA/WPA2 Enterprise (WPA-EAP using TKIP), Hide SSID, MAC/IP Address &URL filtering, Wireless STA (Client) connected list
DHCP DHCP Server, DHCP Client
Network Port Mapping, DMZ Host, Statics Routing, DDNS,UPNP
Management Firmware Upgrade and backup, factory Reset, Restart, WEB management, log management, the PING tool
Product Size 86 x 86 x 30 mm
Product Weight 100g
Package Size 12 x 12 x 7 cm
Package Weight 250g
