ToolkitRC ST8 8CH 100W 2A 7-28V LCD Servo Special Tester PWM/PPM/SBUS Signal Speed Liner Step Servo Analyzer With 4-Ways

Description Brand ToolkitRCItem ST8 Servo TesterChannel 8CH OutputLoad max 100WInput Voltage 7 0 28 0V MAX 10AMain Output Voltage 5 0 28 0V MAX 10ASignal Output Voltage 5 0 8 4V MAX 2A S1 S4 5 8 8 4V MAX 4A S1 S4 Output Signal 100us 2900us 33 1000Hz S1 S4PWM 500us 2500us S5PPM 8CH S5SBUS 16CH S5P1 Button 1000 2000us P1Micro USB Update USB3 0Display 2 4 TFT RGB LCD Screen 320 240 resolution Product Size 96 68 26mm Approx Packing Size 105 80 45mm Approx Net Weight Approx 140gGross Weight Approx 160g Using Steps ① Connect 7 28V power supply After power on the LCD screen displays the logo and continues 2 seconds with the starting music ② Press EXIT button to test PWM signal ③ Totate the Button to choose different channel and press EXIT to confirm ④ Long press the OK button 2s to entra system setting ⑤ Press EXIT to finish setting Features ToolkitRC ST8 is a data analyzer which is capable to test the voltage power current speed and signal data of the servo With 4 way independent programable signal 8 channel signal output the precision is accurating to 1us 4 way independent current date collection and diplayed by graph Support to test multipul date speed liner data steps etc Support multiple signal type PWM PPM SBUS the precision is accurating to 1us Input Voltage is higher to 28V also suitable to test HV servo The max load is upto 100W Multi language system can change the language by yourself USB firmware update easy to oper
