Tomshine 23.5-6000MHz Signal Generator 0.5PPM Low Noise Signal Source Touchable Screen PC Software Control

This is a portable size signal generator and it has powerful functions such as touchable screen PC software control the output frequency ranges is 23.5-6000MHz. This tool can be widely used in wireless infrastructure test and measurement work wireless LANCATV and so on. Features: The signal generator is an ultra-wideband phase-locked loop (PLL) with iegrated voltage controlled oscillator (VCO) capable of working in integer-N and fractional-N modes. With an external reference oscillator and loop filter the signal generator can form a high-performance frequency synthesizer capable of synthesizing frequency ranges of 23.5MHz to 6000MHz while maintaining superior phase noise and spurious specifications. The internal multi-channel integrated VCO covering the ranges of 3000MHz to 6000MHz and the 1-128 output frequency divider are used to realize the output with an ultra-wide frequency ranges. Compatible with 1.8V control logic. The characteristics of the frequency signal source module are that the onboard default high- 25MHz 0.5ppm TCXO the internal VCO base frequency output frequency ranges is 3~6GHz and the base frequency is divided below 3GHz. This frequency signal source module is a full touching screen frequency input the output frequency mode is point frequency and sweeps frequency is optional. The frequency signal source adopts -free 5mmx5mm and the operating ranges is extended to 40°C to 85°C. This tool can be controlled by PC output amplitude is -4~5dBm 4-level touching screen control. Specifications: Material: Printed circuit board Power: ±5V Current: 0.2A Module communication protocol: SPI Output amplitude: - 4~5 dBm Module output frequency ranges: 23.5 ~6000 Inputoutput channel: 1 Working ranges: - 40~85℃ Power supplys interface: Type - C Module output signal: Sinusoidal inputoutput interface module: SMA Item size: 90 * 63 * 15mm / 3.5 * 2.5 * 0.6in Item weight: 60g / 2.1ounce Package size: 130 * 84 * 45mm / 5.1 * 3.3 * 1.8in Package weight: 105g / 3.7ounce Packing list: 1 * Signal Generator 1 * Cable
