Tohuu Wind Turbines Generator Charge Controller DC 14.5-29V MPPT Wind Turbines Generator Charge Controller IP67 Waterproof Wind Turbine Generator Charge Controller Regulator 400W show

Product Description: 1. The wind turbine can be controlled to automatically charge the battery 2. Modular design so that the performance of the whole system is guaranteed to the greatest extent 3. The fully sealed and completely waterproof design is adopted and the protection level has reached IP67 or above. 4. Using MPPT boost charging technology it can be started when the breeze is low and the energy is sufficient which can solve the problem that the fan speed is slow and cannot be charged. Wiring: 1. Connect the positive and negative poles of the battery to the battery positive (red wire) and negative (black wire) terminals of the controller respectively. 2. Connect the three-phase output voltage of the wind turbine to the three-phase input (green wire) terminals of the controller fan respectively. Parameters： 1、Maximum input AC voltage: AC35V; 2、Output DC voltage: DC12V / 24V; 3、Battery charging cut-off voltage: DC14.5V ± 0.3V / 29V ± 0.3V; 4、Maximum charging current: 15A (12V) maximum charging current: 10A (24V); 5、Wind driven generator speed limit voltage DC14.5V ± 0.3V 29V ± 0.3V; 6、Protection level: IP67; 7、Static power consumption: 0.008A; 8、Bearing power: 400W; 9、Maximum bearing wind speed: lvl.12; 10、Working temperature: -35 ° C - 65 ° C 11、Input wiring: three-wire system; 12、Control mode: 12V/24V compatible; 13、Installation method: bolted; 14、Wiring is shown in the schematic figure; do not reverse the positive and negative poles to avoid burning the controller. Product List: Wind Turbine Controller*1
