Tiny 2.4G 6CH Receiver Compatible with DSM2 PPM Signal Output for Eachine QX80 QX90 QX95

Tiny 2 4G 6CH Receiver Compatible with DSM2 PPM Signal Output for Eachine QX80 QX90 QX95Description Item Name Tiny DSM2 ReceiverChannels PWM 5CH PPM 6CHReceiving Sensitivity 99dBmFrequency Range 2 4 2 48GHzPower 3 7 5V DCAntenna Length 30mmSize 9 5mm 10 5mm 2 5mmWeight 0 28gColor Blue Red Send Randomly Features This DSM2 could support all JR and Spektrum transmitter It also could support WALKERA DEVO 10 and DEVO 7E with deviation firmware Support all transmitter which has DSM2 protocol Binding There is no bind pin designed the receiver has an autobind procedure just like with small quad copters When switch on receiver tries to bind with transmitter for about 3s led is blinking If receiver find a transmitter must be also in bind mode then it records transmitter identifier and works with it If it cant bind with a transmitter then is retrieves previously bind transmitter identifier and works with it This way you save an extra pin and just need to bind only once After bind procedure If reception is ok then led on if no reception at all led off if reception bad led is blinking randomly Note CH1 to CH5 is servo signal output If CH1 connect to GND CH2 will output 6CH PPM signal Package Included 1 xTiny DSM2 Receiver
